MODEL 20401
20V CORDLESS
MOUSE SANDER
Instruction Manual
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
1-800-232-1195 (M-F 8AM-5PM CST)
TECHSUPPORT@WENPRODUCTS.COM
IMPORTANT: Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use
your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
WENPRODUCTS.COM
For replacement parts and the most up-to-date instruction manuals, visit
Advertisement
Table of Contents
Related Manuals for Wen 20401
Summary of Contents for Wen 20401
- Page 1 1-800-232-1195 (M-F 8AM-5PM CST) TECHSUPPORT@WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
-
Page 2: Table Of Contents
CONTENTS WELCOME Introduction ..................... 3 Specifications ....................3 SAFETY General Safety Rules ..................4 Mouse Sander Safety Warnings ............... 6 Electrical Information ..................7 Battery & Charger Safety Warnings ..............8 BEFORE OPERATING Unpacking & Packing List ................10 Know Your Mouse Sander ................11 OPERATION &... -
Page 3: Introduction
49120B. Contact WEN customer service at 1-800-232-1195, M-F with questions. WEN plans to continue to add more items to our 20V line. For an up-to-date list of the 20V cordless tools com- patible with the included battery and charger, visit wenproducts.com and search model number 20202 (2Ah) or... -
Page 4: General Safety Rules
GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 5 GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
-
Page 6: Mouse Sander Safety Warnings
MOUSE SANDER SAFETY WARNINGS WARNING! Do not operate the power tool until you have read and understood the following instructions and the warning labels. MOUSE SANDER SAFETY WARNING! This product and the dust created 1. Hold your power tool by the insulated gripping sur- by power sanding, sawing, grinding, drilling, and faces, especially when performing an operation where other construction activities may contain chemicals,... -
Page 7: Electrical Information
ELECTRICAL INFORMATION (CHARGER) DOUBLE-INSULATED CHARGER The charger’s electrical system is double-insulated where two systems of insulation are provided. This eliminates the need for the usual three-wire grounded power cord. Double-insulated tools do not need to be grounded, nor should a means for grounding be added to the product. All exposed metal parts are isolated from the internal metal components with protecting insulation. -
Page 8: Battery & Charger Safety Warnings
Never carry the charger by its cord or yank it by the cord battery chemicals. If the battery or charger are damaged, to disconnect it from the receptacle. Keep the cord away call WEN customer service at 1-800-232-1195 for as- from heat, oil and sharp edges. Make sure the cord will sistance. - Page 9 BATTERY & CHARGER SAFETY WARNINGS ABOUT THE BATTERY 1. The battery pack has to be charged completely before you use the tool for the first time. 2. For optimum battery performance, avoid low discharge cycles by charging the battery pack frequently. 3.
-
Page 10: Unpacking & Packing List
UNPACKING & PACKING LIST UNPACKING Carefully remove the mouse sander from the packaging and place it on a sturdy, flat surface. Make sure to take out all contents and accessories. Do not discard the packaging until everything is removed. Check the packing list below to make sure you have all of the parts and accessories. -
Page 11: Know Your Mouse Sander
TOOL PURPOSE Easily sand corners and very tight spaces with your WEN Mouse Sander. Refer to the following diagrams to become familiarized with all the parts and controls of your mouse sander. The components will be referred to later in the manual for assembly and operation instructions. - Page 12 OPERATION CHARGING THE BATTERY PACK (CONT.) The battery pack is equipped with three LED battery life indication lights. Press and hold the power button on the rear of the battery to check the battery’s charge status. Battery Life Indication: • Three Lights: The battery is fully charged. •...
- Page 13 OPERATION WORKPIECE AND WORK AREA SET UP 1. Designate a work area that is clean and well-lit. The work area must not allow access by children or pets to prevent distraction and injury. We know your cat is super cute, but pay attention to your project. 2.
-
Page 14: Maintenance
WARNING! Any attempt to repair or replace electrical parts on this tool may be hazardous. Servicing of the tool must be performed by a qualified technician. When servicing, use only identical WEN replacement parts. Use of other parts may be hazardous or induce product failure. -
Page 15: Troubleshooting Guide
TROUBLESHOOTING GUIDE WARNING! Stop using the tool immediately if any of the following problems occur. Repairs and replace- ments should only be performed by an authorized technician. For any questions, please contact our customer service at 1-(800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com. Problem Common Causes Solution... -
Page 16: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of normal use are not covered under the warranty. - Page 17 Sandpaper Self-tapping Screw, Flywheel ST3x13 Dust Port, Upper Right Housing Dust Port, Lower Left Housing 20401- Dust Bag 20202 Battery 014ASM 20200C Charger Bushing NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of...
-
Page 18: Warranty Statement
WARRANTY STATEMENT WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN consumer power tools will be free from defects in material or workmanship during personal use for a period of two (2) years used for professional or commercial use. - Page 19 NOTES...
- Page 20 THANKS FOR REMEMBERING V. 2021.02.25...
