3. LAY OUT

A
B
C
D
Fastening result by NG / OK
Numeric LED for the number of fastening screw
126.5 mm
136.5 mm
25P I/O port
Hybrid screwdriver port
- 4 -
Power Input
24VDC,1A
for HDC controller
RS232C Com port
USB
Com port
Menu LCD
Key
dia. 5mm
