6.7 Parameters

P #
P01-
Program #
P08
P09- Minimum tightening
P16 time
P17- Maximum tightening
P24 time
Type of cycle start
P25
and stop
P26 Input signal type
Timer setting for
P27 Cycle start/stop type
2 of P25
Minimum time to
P28
judgement
P29 Com port select
P30 Hybrid HDC connect
Name
Save total number of screws on P1-8.
Minimum screw tightening time
Input : 0.000 - 9.999 sec ( "0" : No use )
Maximum screw tightening time
Input : 0.000 - 9.999 sec ( "0" : No use )
Select one of 4 types of Cycle Start signal
input
0 : Auto
1 : Start (continuous ON)
2 : Start (pulse ON) + Stop (timer on P27)
3 : Start (pulse ON) + Stop (pulse ON)
Select one of 2 signal type
0 : Active High
1 : Active Low
※ When Active Low is selected, the only
one(1) screwdriver ("A") can be connected.
Input screw tightening time limit after Cycle
start signal
Input : 0.0 - 9.9 sec ( "0" : No use )
Set the minimum time to judgement of
OK/NG
Input : 0 - 99 ( x 0.1s ) ( "0" : No use )
Select one of two com ports.
0 : USB
1 : RS-232C
Select one of two condition
0 : Not Connected (not use)
1 : Connected (used)
Specification
