1. Specification
No Description
1 Input power
2 Available tools
3 No of Program
4 Count number
5 Screwdriver port
6 Com port
7 I/O
8 PC software
9 Parameter setting
10 Program share
2. Main features of SCOUT II
- Maximum 5 screwdrivers can share one program of Scout
( 4 of KT-38D v4.3 or FT-40D through A,B,C,D port + 1 extra one through 25P I/O )
- OK / NG judgment for each fastening
- Display of the remained screw number to be fastened
- Variable signal type of the cycle start and stop
- Error display with beep sound
- Display of the fastening error information
- Built in Fastening time measurement function
- No extra power is required for KT-38D, FT-40D
- External power (24VDC) is required for HDC or other tools through 25P I/O
1. 30~40VDC from KT-38D(FT-40D)
2. External power of 24VDC, 1A
for Hybrid controller
KT-38D, FT-40D, HDC-30i, HDC-40i
8 programs
99 for each program
4 ports for KT-38D(FT-40D)
1 port for HDC-30i, HDC-40i
RS232C, USB(B)
Input 15, Output 7
Scout Manager (on Windows)
on front panel or PC software
Maximum 4 screwdrivers (with KT-38D v4.3 or FT-40D)
can share one program
※ Only one(1) KT-38D with the version lower than v4.3
can be connected to Scout II.
- 3 -
