Hub Pilot Wheel Mounting
The hub pilot wheel mounting system uses a single two-piece flange
nut on each wheel stud for both single and dual wheel applications.
The hub pilot wheel mounting system is also referred to as the
Uni-Mount-10™ (10 stud), WHD-10™ (10 stud), WHD-8™ (8
stud) and ISO system. Figure 1.5.
Figure 1.5
SINGLE
WHEEL
Hub PiIot Mounting System
Figure 1.5
2
Meritor Maintenance Manual MM-0637 (Revised 07-12)
DUAL
WHEEL
4005733a
