Taco 0015e3 Instruction Sheet

SUPERSEDES: New
Plant ID No. 001-5024
DESCRIPTION:
The 0015e3® stainless steel is a variable speed, high-efficiency wet rotor circulator with
ECM permanent magnet technology. With 3 easy settings, its performance curves are
equivalent to the versatile Taco 0015 3-speed andideal for hydronic systems zoned
with circulators or zone valves. The 0015e3 reduces power consumptionby up to 85%
compared to equivalent AC permanent split capacitor circulators.
APPLICATION:
• Maximum operating pressure: 150 psi (10 bar)
• Maximum water temperature: 230˚F (110˚C)
• Electrical specifications:
Voltage: 110-120V, 50/60 Hz, single phase
Maximum operating power: 44W
Maximum amp rating: 0.54
• Equipped with a stainless steel casing with
4-bolt universal flanges or 1" union connections
• Use on open loop potable hot water recirculation
systems with up to 1000 feet of pipe or closed loop
hydronic heating systems
• Not suitable for chilled water systems
• Taco circulator pumps are for indoor use only
– employer uniquement a l'interieur
• Acceptable for use with water or maximum of
50% water/glycol solution
FEATURES:
• Three easy settings to match system requirements - LOW, MEDIUM, HIGH
• Replaces all single speed and 3-speed circulators in its class
• Multi-color LED showing operating mode and error code diagnostics
• Nut capture feature on flanges for easier fit up
• Dual electrical knockouts and 6" stranded wire leads for easy wiring
• Double insulated - no ground-wire required
• Whisper quiet operation
• SureStart® - automatic unblocking and air purging mode
• Integral Flow Check (IFC®) included - Field installed
• Green Mode active system monitoring and power optimization
Stainless Steel, Variable Speed
High-Efficiency ECM Circulator
Instruction Sheet
-1-
EFFECTIVE: February 19, 2021
Figure 1:
Model# 0015e3-SF4
Model# 0015e3-SU
Certified to
NSF/ANSI 61 & 372
102-564
