- Page 1 Edu-Logger Light Logger Sensor Guide 900-204...
- Page 2 Hundreds of possible experiments that can be performed with the 900-204 sensor are: Monitoring daily light levels in ecological systems, studying photosynthesis, chemical reactions where light is emitted, studying the effect of changing voltage on a light source’s intensity and light intensity with varying...
- Page 3 Quick start procedure: PC or Mac Computer Materials needed: 900-204 Light Sensor 900-213 USB Module USB to mini USB cable (which comes with the 900-213) Your light sensor needs to be connected to a 900-213 module. The 900-213 module then connects to a computer via a USB to mini-USB cable.
- Page 4 Your light sensor needs to be connected to a 900-268 module. The 900-268 module will create a closed Edu-Logger WiFi network which will stream the Edu- Logger data to the device of your choosing. Once your device is wirelessly connected to the Edu-Logger network you can run experiments and collect data through a browser of your choosing.
- Page 5 LED to the far left turns blue; this can take up to one minute. Take your tablet or smart phone, go to the WiFi settings and select the Edu-Logger network which matches the 900-268 Module ID found on back 900-268 device.
- Page 6 Repeating this operation will return the unit to WiFi mode. Operation with Edu-Logger viewer Materials needed: 900-204 Light Sensor 900-272 Graphic Display Module 900-215 Battery Module Procedure: Connect the light sensor to the left side of the viewer.
- Page 7 (Off-line experiments are when you do not have a sensor connected directly to a computer, tablet, smartphone, or Edu-Logger viewer). Materials needed: 900-204 Light Sensor 900-215 Battery Module Materials needed to configure your offline experiment: 900-213 Module, 900-268 module or 900-272 Module ...
- Page 8 Click the “Load data from sensors” button. Select which experimental data to upload (5 experimental runs can be stored at one time on the 900-204 light sensor). Restoring sensor’s factory default settings: Procedure: Connect the 900-213 to a PC, Mac, tablet, or smart device.
- Page 9 Included with sensor: Edu-Logger 900-204 Light Sensor Guide (this document). Sensor specifications: Range and operation sample Resolution modes resolution rate (in lx) (S/sec) Illumination: 1 lx 0 to 1,000 Illumination: 12 bit 6 lx 3000 0 to 6,000 Illumination:...
- Page 10 This is done by selecting the “Module setup” button on the Light Sensor icon in the Edu-Logger application package when connected. The 900-204 is able to adjust to 3 different sensitivity settings for ambient light because of its ability to...
- Page 11 Maintenance and storage: Never submerge the Edu-Logger plastic body in any liquid. Do not allow liquid into the light sensor’s body. After use, gently wipe away any foreign material from the light sensor.
