Action
Pulses
T
1
T
2
T
T
3
T
Target Selection Mode
Use Target Selection to set the target that the output sees.
1. Access Target Selection mode.
Action
Five-pulse the remote input.
2. Select the desired signal threshold.
Action
Pulses
T
1
T
2
T

5.5 Reset the Sensor to Factory Defaults

Reset the sensor to factory default settings using one of two methods.
Note: If a factory reset is performed through the Banner Radar Configuration Software, the remote input
wire becomes disabled (factory default setting). If the sensor is returned to factory defaults by using the
remote input wire, the input wire remains enabled and the rest of the settings are restored to factory
defaults.
Reset Using the Banner Radar Configuration Software
Go to Sensor > Factory Reset. The sensor indicators flash once, the sensor is reset back to the factory default settings, and
a confirmation message displays.
Reset Using the Remote Input
Eight-pulse the remote input to apply the factory defaults.
T T T T T T
T T T T T
TEACH Mode
Speed = Fast
T
Speed = Medium
T T
Speed = Slow
T
TEACH Mode
Nearest Target—Output responds
to the nearest target that is over
the signal strength threshold.
Strongest Target—Output
T
responds to the target with the
highest signal strength that is over
the signal strength threshold.
T T
T T
www.bannerengineering.com - Tel: + 1 888 373 6767
T T T T T
T T
T T
R-GAGE
Result
The speed is set and the power LED flashes
equal to the number of pluses, pauses, and
then flashes equal to the number of pulses a
second time. The sensor exits remote teach
and returns to run mode.
Result
The green power LED flashes slowly.
Result
The signal threshold is set and the green
power LED flashes equal to the number of
pluses, pauses, and then flashes equal to
the number of pulses a second time. Then
the sensor exits remote teach and returns to
run mode
®
T30R Sensor
