Banner WORLD-BEAM QS30 Series Manual

Excellent for applications where high sensing power and small beam size are important. Operates over
sensing ranges typically accomplished only by conventional opposed-mode photoelectrics; uses a special
filter to polarize the emitted light, filtering out unwanted reflections from shiny objects.
Range and
Model
Use
0.2 to 18 m
QS30LLP
(0.67' to 60')
Maximum
Excess Gain
SET for
QS30LLPQ
Long-Range
Applications
0.2 to 18 m
QS30LLPC
(0.67' to 60')
Low-Contrast
SET for
Small Object
QS30LLPCQ
Detection
*9 m (30') cables are available by adding suffix "
A model with a QD connector requires a mating cable (see page 10).
! WARNING . . .
Never use this product as a sensing device for personnel protection. Doing so could lead to serious injury or death.
This product does NOT include the self-checking redundant circuitry necessary to allow its use in personnel safety applications.
A sensor failure or malfunction can cause either an energized or de-energized sensor output condition. Consult your current Banner Safety
Products catalog for safety products which meet OSHA, ANSI and IEC standards for personnel protection.
Printed in USA
WORLD-BEAM
Polarized Retroreflective Laser Sensors
• Visible class 1 laser with small, effective beam size
• Excellent optical performance throughout sensing range, even close up
• Easy push-button SET options: Maximum Excess Gain or Low-Contrast SET,
depending on model, plus Manual Adjust
• Easy-to-read operating status indicators, with 8-segment bargraph display
• Bipolar discrete outputs, PNP and NPN
• Selectable 30 millisecond OFF-delay
• Models available with 2 m or 9 m (6.5' or 30') cable or integral quick-disconnect
• Tough ABS housing rated IEC IP67; NEMA 6
• Compact housing, mounting versatility – popular 30 mm threaded nose or
side-mount
Spot
Size at Cable* Supply
Focus
2 m (6.5')
5-wire Cable
Integral
5-pin
Approx.
Euro-style
4 mm
QD
10 to
at 10 m
30V dc
(0.16"
2 m (6.5')
at 33')
5-wire Cable
Integral
5-pin
Euro-style
QD
W/30
" to the model number of any cabled sensor (e.g.,
Not To Be Used for Personnel Protection
®
QS30 Series
Features
Models
Output
With Supplied Target
Type
BRT-36X40BM
1000
E
X
C
100
E
S
S
Bipolar
G
10
A
NPN/PNP
I
N
1
0.1 m
0.33'
QS30LLP W/30
09/04
P
Visible Red, Class 1 laser; 650 nm
Excess Gain
With Supplied Target
BRT-TVHG-2X2
1000
with BRT-36X40BM
E
X
C
100
E
S
S
G 10
A
I
N
1
1.0 m 10 m 100 m 0.1 m 1.0 m
3.3' 33' 330'
0.33' 3.3'
DISTANCE
DISTANCE
).
P/N 112355 rev. A
with BRT-TVHG2X2
10 m 100 m
33' 330'
