Malfunction signalled by the transmitting unit

6 Malfunction signalled by the transmitting unit
Use the light signals on the transmitting unit to identify the radio remote control malfunction.
If the problem persists after the suggested solution has been carried out, contact the support
service of the machine manufacturer.
Signals
The green LED does not
switch on when the START
pushbutton is pressed, even
though both the battery and
the S-KEY are inserted.
The green LED blinks fast.
The red LED switches on for
2 seconds and then the unit
switches off.
The red LED blinks once
during start up.
The red LED blinks twice
during start up.
The red LED blinks three
times during start up.
The red LED blinks four
times during start up.
c. Procedure to save the address
- press the STOP pushbutton
- press the START pushbutton and do not release it until the green LED switches off
- unlock the STOP pushbutton
AUTEC - DYNAMIC SERIES
Possible reason
The battery is flat.
No radio link.
The transmitting unit does not
work correctly.
The STOP pushbutton is
locked or damaged.
At least one of the actuators
corresponding to commands
D2-D20 and SAFETY is
activated or damaged.
The battery is flat.
At least one of the actuators
corresponding to commands
A1-A8, L1-L8, H1-H8 and
SAFETY is activated or
damaged.
Solutions
Replace the battery with a
charged one.
Bring the transmitting unit
close to the receiving unit.
Perform the procedure to save
the address .
c
Contact the support service of
the machine manufacturer.
Unlock the STOP pushbutton.
If this signal persists, contact
the support service of the
machine manufacturer.
Bring the actuators to the rest
position. If this signal persists,
contact the support service of
the machine manufacturer.
Replace the battery with a
charged one.
Bring the actuators to the rest
position. If this signal persists,
contact the support service of
the machine manufacturer.
