Technical data sheet

3 Technical data sheet
The technical data sheet contains the transmitting unit configuration and shows the matching
between commands sent and machine functions/movements. It also contains the wiring
diagram showing the connection between the receiving unit and the machine.
Each technical data sheet must be filled in, checked and signed by the installer, who is
responsible for a correct wiring.
A copy of the technical data sheet must always be kept together with this manual (always
keep a copy of this data sheet for administrative purposes).
The wiring of the receiving unit outputs must always reflect the wiring
indicated in the technical data sheet.
4

Plates

The transmitting unit has the following plates:
Plate
radio remote control
identification plate
transmitting unit
identification plate
technical data plate
AUTEC - DYNAMIC SERIES
Position
On the S-KEY: remove the S-KEY to
read the plate.
In the battery housing: remove the
battery to read the plate.
In the battery housing: remove the
battery to read the plate.
Content
Radio remote control
serial number (S/N)
Manufacturing year, bar
code and transmitting
unit identification number
(TU ID).
MODEL, TYPE and
main transmitting unit
technical data, marking
and possible radio remote
control marks.
LIFJLE00-03
