Matrix CXP Manual page 6

ASSEMBLY
1
Hardware Qty
A Bolt (M12x25L) 4
B Flat Washer 4
2
Hardware Qty
D Stopper 1
E Screw (M8x20L) 1
F Screw (M4x6L) 2
B
A
B
A
Torque Value
78 Nm / 58 ft-lb.
D
E
Slide handlebars onto frame
before attaching (D), (E) and
then (F)
Torque Value
E - 20 Nm / 14 ft-lb
ENGLISH
3
Pre-installed Hardware
G Screw (M6x50L)
Torque Value
G - 10 Nm / 7.4 ft-lb
F
Hardware
H Screw (M3x12L)
6
Qty
1
G
40 Nm / 29.5 ft-lb
Qty
4
LEFT PEDAL
