- Page 1 PRO-2200 Remote Enclosure Installation Manual Part Number: PRO22ENC3 A division of Northern Computers, Inc. TD1144 rev 0801...
-
Page 2: Table Of Contents
Product Liability; Mutual Indemnification..............6 Unpacking Procedure ................... 6 Shipping Instructions .................... 6 Limited Warranty ....................7 Confidentiality ..................... 7 PRO-2200 Remote Enclosure ................8 Description ......................8 Dimensions ......................8 Conduit Knockouts ....................8 Power Supply ....................... 9 LED Diagnostics....................9 Backup Power Supply ................... -
Page 3: Warnings And Cautions
Always make certain that any required approvals are obtained in writing. DO NOT ACCEPT VERBAL APPROVALS, THEY ARE NOT VALID. Engineered Systems never recommends using the PRO-2200 Series or related products for use as a primary warning or monitoring system. Primary warning or monitoring systems should always meet local fire and safety code requirements. - Page 4 PRO-2200 Remote Enclosure—PRO22ENC3 Installation Guide CAUTION IF ANY DAMAGE TO THE SHIPMENT IS NOTICED, A CLAIM MUST BE FILED WITH THE COMMERCIAL CARRIER RESPONSIBLE. CAUTION Electro-static discharge can damage CMOS integrated circuits and modules. To prevent damage always follow these procedures: Use static shield packaging and containers to transport all electronic components, including completed reader assemblies.
-
Page 5: Disclaimer
PRO-2200 Remote Enclosure—PRO22ENC3 Installation Guide Disclaimer Product Liability; Mutual Indemnification In the event that a Customer receives a claim that a Product or any component thereof has caused personal injury or damage to property of others, Customer shall immediately notify Engineering Systems in writing of all such claims. Engineering Systems shall defend or settle such claims and shall indemnify and hold Customer harmless for any costs or damages including reasonable attorneys’... -
Page 6: Limited Warranty
PRO-2200 Remote Enclosure—PRO22ENC3 Installation Guide Obtain the Return Authorization Number (RMA) from the customer service department at 800-323-4576. Show the RMA number on all packages shipped. Packages, which are not marked with an RMA number will be refused at the factory and returned COD. -
Page 7: Pro-2200 Remote Enclosure
PW-5000 Remote Enclosure Description The PRO-2200 Remote Enclosure allows for a variety of system configurations. It can be used in combination with the PRO22ENC1, for example to place modules closer to the doors they control. Or it can be used alone to house modules for a smaller system. -
Page 8: Power Supply
PRO-2200 Remote Enclosure—PRO22ENC3 Installation Guide Power Supply DO NOT USE POWER SUPPLY TO POWER LOCKS - 12 VDC 2 amp continuous power limited output with backup battery charging and battery supervision. - A 16.5 VAC 20 VA wall transformer is provided. -
Page 9: Pro-2200 Remote Enclosure
PRO-2200 Remote Enclosure—PRO22ENC3 Installation Guide PRO-2200 Remote Enclosure 14.725 7.850 .975 11.875 9.020 13.385 6.840 4.660 9.300 .4975 LEFT SIDE .930 .760 14.940 BACK 16.015 1.700 13.675 11.875 13.985 9.020 6.840 4.660 .990 RIGHT SIDE FRONT 4.120 1.70 1.700 .990 .990... -
Page 10: Installation Instructions
This enclosure can mount two full size PRO-2200 panels OR one full size panel, one PRO22R1 single reader panel and one PRO22MX8 multiplexer panel. -
Page 11: Installation Diagram 2
Left Open View Right Open View POWER IND LIGHT WIRE ASSEMBLY 1-REQ'D KURLY RETAINING 4 REQ'D RING 1-REQ'D WALL PRO22ENC3 TRANSFORMER **IMPORTANT** **IMPORTANT** 1 REQ'D (X-5) SUPPRESSORS MUST BE USED ENCLOSURE MUST BE SN/1234 date EARTH GROUNDED WITH STRIKES, NORTHERN S-4 code PRO22E3PS AC FAIL... -
Page 12: Cable Specifications
PRO-2200 Remote Enclosure—PRO22ENC3 Installation Guide Cable Specifications Application NCI Part No. Description Max. Dist. Imp. Cap. N-485 connections NC2442-TN Belden 9842 4000' (1200 m) 120Ω 12.8pf/ft or equivalent CR-1, TR-1, CI-1, KR-1 NC1861-BL 6 conductor shielded 500' (152 m) Wiegand card readers... -
Page 13: Nci Cable Part Numbers
PRO-2200 Remote Enclosure—PRO22ENC3 Installation Guide NCI Cable Part Numbers Part Number Description Application Length NC1841-GY 18 AWG/4 conductor reader cable 1,000' NC1861-BL-500 18 AWG/6 conductor reader cable 500' NC1861-BL 18 AWG/6 conductor reader cable 1,000' NC18121-YL-500 18 AWG/12 conductor keypad cable... - Page 14 PRO-2200 Remote Enclosure—PRO22ENC3 Installation Guide...
- Page 15 Honeywell Security & Data Collection 2700 Blankenbaker Pkwy, Suite 150 Louisville, KY 40299 (800) 675-3364 www.honeywellaccess.com...
