On-Off Control
Temperature Scale
Relay 1 Control
Relay 2 Control
Relay 3 Control
Relay 4 Control
Relay 5 Control
Relay 6 Control
Relay 7 Control
Occupancy
Command
Fan Output for
Heating
Heartbeat
MSV 0
Fan Mode
System Mode
Sleep
Temperature Source
Lowest Fan
Speed
Fan Speed Status
Display Options
UM-15093500-AA1
BV 5 R/W
BV 6 R/W
BV7 R/W
BV8 R/W
BV9 R/W
BV10 R/W
BV11 R/W
BV12 R/W
BV13 R/W
BV 14 R/W
BV15 R/W
BV16 R/W
R/W
MSV 1 R/W
MSV 2 R/W
MSV3 R/W
MSV 4 R/W
MSV 5 R
MSV 6 R/W
On/Off Status of Thermostat 0: Off, 1: On
°C/ °F
On/Off Control of Relay 1
On/Off Control of Relay 2
On/Off Control of Relay 3
On/Off Control of Relay 4
On/Off Control of Relay 5
On/Off Control of Relay 6
On/Off Control of Relay 7
(Fan)
Room Occupancy Setting
Disable/ Enable Fan
Output for Heating
Communication
Heartbeat Flip-Flop
Fan Mode
Working Mode: Heat, Cool or
Ventilation
Sleep (Only for Models with
Sleep Function Available).
Current Temperature Source
Lowest Fan speed in
Auto Fan mode
Fan Speed Status
LCD Display Options
0: °C
1: °F
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Occupied,
1: Unoccupied
0: Disable
1: Enable
0: Off
1: On
1: Auto 2: Low 3: Med.
4: Hi
1: Cool Mode
2: Heat Mode
3: Ventilation @ Cool Mode
4: Ventilation @ Heat Mode
1: Disable,
2: 0 Hr. Sleep
3: 0.5 Hr. Sleep
4: 1 Hr. Sleep
5: 1.5 Hrs. Sleep,
6: 2 Hrs. Sleep
1: Built-In Temp. Sensor
2: Remote Temp. Sensor
3: Assigned through BACnet
1: Stop 2: Low
3: Med. 4: Hi
0: Stop 1: Low 2: Med
3: Hi
1: T & Time (if available) 2:
SP & Time (if available) 3: T
& CO2 (if available)
4: CO2 & Time (if available)
