Minimum Cooling
Setpoint
Maximum Heating
Setpoint
Minimum Fan
Output
Maximum Fan
Output
Low Fan Speed
Setting
Med. Fan Speed
Setting
Hi Fan Speed
Setting
Minimum Off
Time
Minimum On Time
Integral-Cycle
Time 2
Set Point for
Humidity
Dew Point Set
Point
Occupancy Status
Window-Door Status
Cooling-heating
Status
Relay 1 Status
Relay 2 Status
Relay 3 Status
Relay 4 Status
Relay 5 Status
Relay 6 Status
UM-15093500-AA1
AV 39 R/W
AV 40 R/W
AV 41 R/W
R/W
AV 42
AV 43 R/W
AV 44 R/W
AV 45 R/W
AV 46 R/W
AV 47 R/W
AV 48 R/W
AV 49 R/W
AV 50
R/W
BI 0 R
BI 1 R
BI 2 R
BI 3 R
BI 4 R
BI 5 R
BI 6 R
BI 7 R
BI 8 R
Minimum Cooling Setpoint
Maximum Heating Setpoint
Minimum Fan Output at Auto
Fan Mode (for Modulating
Fan Application)
Maximum Fan Output at
Auto Fan Mode (for
Modulating Fan Application)
Low Fan Speed Setting (for
Modulating Fan Application)
Med. Fan Speed Setting (for
Modulating Fan
Application)
Hi Fan Speed Setting (For
Modulating Fan Application)
Minimum Off Time
Minimum On Time
Integral Time and Output
Cycle Time 2
Set Point for Humidity
Control
Dew Point Temperature
Set Point
Status of Occupancy
Window/ Door Status
Status of Cooling/Heating
Control
Output
Status of Relay 1
Status of Relay 2
Status of Relay 3
Status of Relay 4
Status of Relay 5
Status of Relay 6
°C:0~500 (0.0～50.0℃)
°F: 320~1220
)
(32.0~122.0°F
°C:0~500 (0.0～50.0℃)
°F: 320~1220
(32.0~122.0°F)
0%~Reg 51
Reg 50~100%
0%~Reg 53
Reg 52~Reg54
Reg 53~100%
0~600 seconds
0~600 seconds
0~500 (Sec.)
0~1000 (0.0～100.0%RH)
℃/°F
-999~9999: -99.9～999.9
0: Room Occupied
1: Room Unoccupied
0: Door/Window Closed
1: Door/Window Open
0: Close & Off 1: Open & On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
