Contemporary Controls BASstat BAST-421C-BW2 User Manual page 32

Modulating/floating
Control Out
Percentage
AV 19
Device Instance AV 20
UDP Port No
AV 21
AV 22
Humidity Offset
AV 23
Cooling Short Cycle
Delay
Cooling Maximum
AV 24
Cycles per Hour
Heating Short Cycle
AV 25
Heating
AV 26
Maximum Cycles
per Hour
Analog Minimum
AV 27
Output for AO2
Span Offset for
AV 28
AO2
Heartbeat Rate
AV 29
Humidity
AV 30
Proportional Band-
Stage Width
Humidity Stage
AV 31
Differential
Proportional Band
AV 32
or Stage Width 2
CO Offset
AV 33
2
After Hour Extension
AV 34
Run Time
Input Low Value
AV 35
Input High Value
AV 36
Options
AV 37
DI Contact Definition
AV 38
UM-15093500-AA1
Percentage of Modulating/
Floating Control Output
R/W
R/W Device Instance
UDP Port Number
R/W
R/W
Humidity Offset Value
(CH models only)
R/W
Cooling Short Cycle Delay
Cooling Maximum Cycles
R/W
per Hour
Heating Short Cycle Delay
R/W
Heating Maximum Cycles
R/W
per Hour
Minimum Output Voltage in
R/W
Digital Value When Reach
Low Limit for AO2
Span Offset for AO2
R/W
Communication Heartbeat
R/W
Minimum Rate
Proportional Band or Stage
R/W
Width for Humidity Control
Output
Stage Differential for
R/W
Humidity Control Output
Proportional Band or Stage
R/W
Width 2
CO Offset Value
R/W
2
After Hour Extension Run
R/W
Time
Input Low Value
R/W
Input High Value
R/W
Options
R/W
DI Contact Definition
R/W
0～100 (0%～100%)
0~4194302
(Note: Changing this value
needs to unlock modification
for communication
parameters in advance.
i.e. AV17=0~255 or
512~768. Please refer to
LOCK(AV17) for details)
0~65535
-300~300 (-30.0～30.0
%RH)
1~3 Minutes
2~6 Cycles
0~3 Minutes
2~8 Cycles
0~125 (LSB)
-55~0 (LSB)
10~3600 s
0~1000 (0.0~100.0)
%RH
0~1000 (0.0~100.0)
%RH
°C :0~100 (00~10.0 °C)
°F: 0~180 (00~18.0 °F)
-1000~2000 ppm
5~20(0.5~2.0) Hour
-1000~1000 (-100.0～
100.0 %)
0~1000 (0.0～100.0 %)
Bit Definition --- Bit 0: T or SP
Bit 1~15: Reserved
Bit Definition --- Bit 0: DI-1
1: DI-2
Bit 2~15: Reserved
*Bit value:0-NO, 1-NC
Page 31
