Contemporary Controls BASstat BAST-421C-BW2 User Manual page 22

Item Mnemonic
E57 Phy3 MAC address 5th & 6th bytes
E58 IP-1 1st byte of IPv4 address
E59 IP-2 2nd byte of IPv4 address
E60 IP-3 3rd byte of IPv4 address
E61 IP-4 4th byte of IPv4 address
E62 tESt Self-Diagnostic – toggle all LCD features and
all relays. Use only to test
E63 boot Reset Wi-Fi parameters to factory defaults
E64 rSt Reset all parameters including communication
and control algorithm to the factory defaults
E65
End Exit Engineer Mode Menu
** Note: 1. Changing these values needs to unlock modification for communication parameters in
advance. Please refer to the parameter LOC(Lock, AV17) for details.
2. Device instance number = "devH" *1000 + "devL" = 0~4194302. ex. If "devH" is 100 and devL"
is 001then the Device instance number = 100001.
Lock Function Setup and Examples
The 16-bit binary encoded decimal register accessed through Lock [AV17] BACnet object and LOC
engineering menu item is used to enable/disable features in the thermostat. The first 10 bits are used
(bit 0 ~ bit 9), bits 10~15 are reserved/unused. Bits are represented by their decimal values and are
added or subtracted to toggle from "0" to "1". Add a bit's decimal value to toggle to "1" or subtract a bit's
decimal value to toggle to "0". See table below.
UM-15093500-AA1
Description
°C Scale
Default Range Default
hhhh
192 0~255 192
168 0~255 168
0 0~255 0
1 0~255 1
°F Scale
Step
Range
hhhh
h: 0~F in hex
0~255
1
0~255
1
0~255
1
0~255
1
Use
Press MODE to
Caution!
engage test
Press MODE to
reset
Use
Press MODE to
Caution!
reset
Press MODE to
exit engineering
menu
Page 21
