Installing the Device
2.1 General Procedure
This product contains no user-serviceable parts. Attempted service by unauthorized
personnel shall render all warranties null and void.
Changes or modifications not expressly approved by Siemens Canada Ltd. could
invalidate specifications, test results, and agency approvals, and void the user's
authority to operate the equipment.
This product should be installed in a restricted access location where access can only
be gained by authorized personnel who have been informed of the restrictions and
any precautions that must be taken. Access must only be possible through the use
of a tool, lock and key, or other means of security, and controlled by the authority
responsible for the location.
2.1

General Procedure

The general procedure for installing the device is as follows:
Note
The user is responsible for the operating environment of the device, including
maintaining the integrity of all protective conductor connections and checking
equipment ratings. Make sure to review all operating and installation instructions
before commissioning or performing maintenance on the device.
1.
2.
3.
4.
5.
6.
7.
2.2

Unpacking the Device

When unpacking the device, do the following:
1.
2.
6
NOTICE
NOTICE
Review the relevant certification information for any regulatory requirements.
For more information, refer to
Review the "RUGGEDCOM RX1500 Series Modules Catalog" for special
installation or regulatory requirements related to the modules installed in
the device. In the case of cellular modem line modules, this includes antenna
installation and regulatory requirements.
Mount the device.
Connect the failsafe alarm relay.
Connect power to the device and ground the device to safety Earth.
Connect the device to the network.
Configure the device.
Inspect the package for damage before opening it.
Visually inspect each item in the package for any physical damage.
"Approvals (Page 37)".
