1 INTRODUCTION

1.1

ABOUT THIS MANUAL

This integration manual explains how to integrate ELATEC RFID reader module TWN4 MultiTech 2 M BLE into a host device and is
mainly intended for integrators and host manufacturers.
The content of this integration manual is subject to changes without prior notice and printed versions might be obsolete. Integrators
and host manufacturers are required to use the latest version of this integration manual.
For the sake of better understanding and readability, this manual might contain exemplary pictures, drawings and other illustrations.
Depending on your product configuration, these pictures might differ from the actual design of your product.
1.2

ABOUT TWN4 MULTITECH 2 M BLE

The TWN4 MultiTech 2 M BLE reader module has integrated RFID (LF & HF) and Bluetooth Low Energy (BLE), which is supported by
mobile phones with Android version 4.3 or greater, iOS 8.0 or greater and PCs with Windows (new Bluetooth hardware integrated).
The app on the reader communicates with the BLE module with easy commands and has direct enhancement to the GATT structure,
which gives you the flexibility to write your custom apps.
1.3

ELATEC SUPPORT

In case of any technical questions, refer to the ELATEC website (www.elatec.com) or contact ELATEC technical support at:
support-rfid@elatec.com
1.4

REVISION HISTORY

VERSION
02 Chapters "Safety Information" and "Compliance Statements" updated
01 First edition

2 SAFETY INFORMATION

•
ELATEC TWN4 MultiTech 2 M BLE is an electronic component and should be installed exclusively by a trained and qualified
personnel.
•
ELATEC recommends the integrators to follow general ESD protective measures during the installation of
TWN4 MultiTech 2 M BLE into a host device, e.g. the use of an antistatic wristband or special gloves.
•
The integrator should not touch the antennas (if not shielded), printed circuit boards, connectors or other sensitive components on
TWN4 MultiTech 2 M BLE.
•
Before installing TWN4 MultiTech 2 M BLE into a host device, the integrator should also make sure that he/she has read and
understood the ELATEC technical documentation related to TWN4 MultiTech 2 M BLE, as well as the technical documentation
related to the host device. In particular, the instructions and safety information given in the user manual of
TWN4 MultiTech 2 M BLE should be read carefully and listed in the technical documentation of the host manufacturer as well, as
soon as these instructions and safety information are required for a safe and proper use of the host device containing
TWN4 MultiTech 2 M BLE.
© 2021 ELATEC GmbH – TWN4 MultiTech 2 M BLE integration manual DocRev2 – 07/2021
CHANGE DESCRIPTION EDITION
07/2021
05/2021
Page 3 of 10
