INSTALLATION MANUAL
800|900|1000
Premium Series
30 Day Technical Support:
Call 01908 317512 and request technical support for aiding your
installation.
Replacements Parts:
https://www.insigniashowers.com, click support and make a
warranty claim.
Spares/Replacements Parts:
https://www.insigniashowers.com/replacement-parts.html
ATTENTION INSTALLERS:
These instructions must be
left with the customer
www.insigniashowers.com
Inside of your warranty period visit:
Outside of your warranty period visit
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
WARRANTY REG NO: _______________________
To claim your full 2 year warranty, register your shower within 90 days visit:
https://www.insigniashowers.com, click support and register for your warranty
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!
Last Modified 17/05/2021
Advertisement
Table of Contents
Related Manuals for Insignia Premium Series
Summary of Contents for Insignia Premium Series
- Page 1 Last Modified 17/05/2021 INSTALLATION MANUAL 800|900|1000 Premium Series 30 Day Technical Support: Call 01908 317512 and request technical support for aiding your installation. Replacements Parts: Inside of your warranty period visit: https://www.insigniashowers.com, click support and make a warranty claim.
-
Page 2: Table Of Contents
www.insigniashowers.com Last Modified 17/05/2021 Contents Water Valve Connections Installation Assistance (Video Links) Control Panel Connections Thank you for your purchase Tips for assembly Steam Generator Connections Braided Hose QR Code/Link Signing off your shower Control Panel Operating Instructions Electrical/Pressure/Tool requirements Spare Parts List Box contents Steam Room &... -
Page 3: Installation Assistance (Video Links)
Simply click the link below and watch the installation process. Shower Install Please note: this build video is for an Insignia Platinum Shower, however 90% of the process is the same for assembly so it should help you on your way! - Page 4 Last Modified 17/05/2021 Thank you for your recent purchase of an Insignia shower. Please read this booklet with great care to ensure you get the best out of your build and have a shower that will last for many years to come! Like everything, in order to obtain a first class product that will serve you well for many years, the effort and correctness put into the assembly will reflect in the quality of your finish.
- Page 5 TIP 4—Sealing When using Insignia’s RubberGum, please ensure the product does not come in contact with your silicone as this will cause the RubberGum to fail and will not adhere as intended. Rubbergum is immediately waterproof and will gain additional strength over time.
- Page 6 www.insigniashowers.com Last Modified 17/05/2021...
- Page 7 www.insigniashowers.com Last Modified 17/05/2021 Electrical Requirements Pressure/Water Requirements Tools Required STEAM VERSION We recommend a BAR pressure between 2.5 and 3.4 BAR. If You will require: you have a combi boiler system no problem should be Voltage Rating 220-240AC • •...
-
Page 8: Box Contents
10mm Screws ST16 16mm Screws VERY IMPORTANT ST20 or WN20 20mm Nut and Bolt or Wing Nut Have you got everything? If not please contact the Insignia directly on 01908 317 512. AMI01 Jubilee Clip (For steam version only) Remember NEVER book your tradesman until everything has arrived, been checked and is present. - Page 9 www.insigniashowers.com Last Modified 17/05/2021 Step 1 — Level the Tray and connecting the waste Twist to adjust NOTE: FOR STEAM SHOWERS ONLY: Check the Spigot is drilled out prior to fitting. If it isn’t ensure you drill it out!
- Page 10 www.insigniashowers.com Last Modified 17/05/2021 Step 2 — Connecting framework Framework securing clips x4 Internal View Wider rail on top Narrow rail at the bottom...
- Page 11 www.insigniashowers.com Last Modified 17/05/2021 Step 3 — RubberGum the tray Apply RubberGum to raised sections of the tray and remove backing paper. Step 4 — Fix framework to the tray PRESS FRAME DOWN FIRMLY ONTO THE RUBBERGUM.
- Page 12 www.insigniashowers.com Last Modified 17/05/2021 Step 5 — Connecting the back panels ST16 x12 PRESS PANELS DOWN FIRMLY ON TO THE RUBBERGUM. DO NOT SCREW BACK PANELS TO THE TRAY.
- Page 13 www.insigniashowers.com Last Modified 17/05/2021 Step 6 — Column Connection ST20 x 12 SW9 x 12 WN20 x 12 Rear View (attach nuts and bolts or wing nuts from rear) Below diagram shows the nut/bolt install ———————— ———————— NOTE: Column features varies between models...
- Page 14 www.insigniashowers.com Last Modified 17/05/2021 Step 7 — Fixed Glass Connection ST16 x 2 Internal View Use outer hole Slide glass in Repeat process for other side Attach Upright...
- Page 15 www.insigniashowers.com Last Modified 17/05/2021 Step 8 — Fitting the glass seals Fit seal inside the shower between the glass and framework 12mm 2x 12mm Seals 2x 7mm Seals Step 9 — Fitting the door stops Internal View — Top Rail ST10 x8 SP072 x8 Internal View —...
- Page 16 www.insigniashowers.com Last Modified 17/05/2021 Step 10 — Attaching the Roof Screw from the rear ST16 x6 Step 11 — Fit door handles, seals and magnets...
- Page 17 www.insigniashowers.com Last Modified 17/05/2021 Step 12 — Fit top door wheels x 4 Tighten to secure wheels into door runners. DO NOT OVERTIGHTEN Slide cover off Door Step 13 — Fit bottom door wheels x 4 Slide cover off Door Step 14 —...
- Page 18 www.insigniashowers.com Last Modified 17/05/2021 Step 15 — Accessory Installation Slide cover off Slide cover off...
- Page 19 www.insigniashowers.com Last Modified 17/05/2021 Step 16 — Valve/Water Connections Monsoon Head Jets Hand Shower 2 x Washers located on the back of the valve Cold Water Inlet Hot Water Inlet Outlet for Steam version only...
-
Page 20: Control Panel Connections
www.insigniashowers.com Last Modified 17/05/2021 Step 17 — Control Panel Connections Premium Steam Premium Version Version Roof Light Power Supply Speaker Antenna Speaker... -
Page 21: Steam Generator Connections
Water Inlet: When installing the water line for the steam generator, there are 2 options available: • Purchase Insignia’s WRAS approved braided hoses—different packs are available for different shower types. • Install a static water line from the shower valve (middle feed) to the steam generator. Even with a static water line, flexible hosing will still be required for the hot and cold water feeds. -
Page 22: Signing Off Your Shower
3. Do not aim the hand shower directly at the joints of your shower as this does not fall under “normal showering conditions”. However, due to Insignia’s unique design of the shower tray, water will only leak back in to the tray so you won’t get flooded. -
Page 23: Control Panel Operating Instructions
Press once to turn on the panel. Simply press again to turn it off. When powering down the 03 will automatically start and last for approximately 10 minutes. After this the screen will power off. To see our tutorial videos for operating Insignia control panel’s, please search for “Insignia Showers” on YouTube and find our “Insignia Control Panel”... - Page 24 www.insigniashowers.com Last Modified 17/05/2021 Control Panel Instructions Connecting to Bluetooth Step 2 Step 1 Then simply go on your device and pair To connect a device via up with the shower which should be Bluetooth, press the music shown as “INS”. Once this is complete function button twice (which you will hear a beep to signify you’re looks like a musical note) the...
- Page 25 When the Bluetooth is activated this will skip to the next song in your playlist. To see our tutorial videos for operating Insignia control panel’s, please search for “Insignia Showers” on YouTube and find our “Insignia Control Panel” Playlist, or you can...
- Page 26 Last Modified 17/05/2021 Parts List Part Code Part Description SP337 Insignia Control Panel (non SP300 Waste hose -steam version only) SP010 Monsoon Shower head SP301 White insulated pipe (steam version only) SP078 Ozone Module (steam version only) SP117 Insignia Control Panel...
-
Page 27: Steam Room & Shower Safety Guide
www.insigniashowers.com Last Modified 17/05/2021 Steam Room & Shower Safety Guide Never leave children unattended in the shower or bath. Never bath children (under 12) using whirlpool function if fitted. Regulate the temperature of water before showering. Never allow children to use the steam function. This function is for ADULTS ONLY. Always be aware of the steam outlet position. -
Page 28: Steam Room Usage Guide
www.insigniashowers.com Last Modified 17/05/2021 Steam Room Usage Guide To use the steam room, turn the control panel on. (1) Press the steam button (2) and your generator will be fed with water and the heating element will begin to heat the water to create steam. (You should be seeing steam from your outlet in approximately 60-90 seconds) To set the temperature you want the cabin to reach, press the function button (3) once the steam is active. -
Page 29: Bathroom Electrical Zones
www.insigniashowers.com Last Modified 17/05/2021 Bathroom Electrical Zones... - Page 30 www.insigniashowers.com Last Modified 17/05/2021 There are 3 bathroom electrical zones that have been distinguished in the IEE wiring guidelines and these are: Zone 0 is the area inside a bath, basin or shower. It's characterised as 'any area within a bathroom that can hold water'. Any fitting or electrical appliance utilised inside zone 0 must be a maximum of 12 volts (SELV) and completely secured against both partial and total submersion in water (minimum of IPX7) Zone 1 is the region straight above zone 0 to the height of 2.25m from the base of the bath or shower.
-
Page 31: Weee Compliance Statement
(EEE) have to fulfil certain obligations. Under the WEEE directive Insignia is considered the producer of certain products we supply and in line with the demands of the legislation we are pleased to offer the op- portunity to return these products to us for treatment and recycling. - Page 32 www.insigniashowers.com Last Modified 17/05/2021...
