INSTALLATION MANUAL
1400x900
Premium Series
30 Day Technical Support:
This service is only available to customers from
the day of delivery Mon-Fri 10:30-15:30, please
have your supplier's details and your postcode to
hand before calling.
Replacements Parts:
period contact: www.insigniarange.co.uk/support
Spares/Replacements Parts:
warranty period visit www.insigniaoutlet.co.uk
ATTENTION INSTALLERS:
These instructions must be
left with the customer
www.insigniarange.com
01908 226545
Inside of your warranty
Outside of your
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
WARRANTY REG NO: _______________________
To claim your full 2 year warranty, register your shower within 90 days at: www.insigniarange.co.uk/warranty
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!
Last Modified: 20/08/2020

Advertisement

loading

Related Manuals for Insignia Premium Series

Summary of Contents for Insignia Premium Series

  • Page 1 Last Modified: 20/08/2020 INSTALLATION MANUAL 1400x900 Premium Series 30 Day Technical Support: 01908 226545 This service is only available to customers from the day of delivery Mon-Fri 10:30-15:30, please have your supplier’s details and your postcode to hand before calling.
  • Page 2 www.insigniarange.com Last Modified: 20/08/2020 Contents Thank you for your purchase Valve/Water Connections Tips for assembly Control Panel Connections Electrical/Pressure/Tool requirements Steam Generator Connections Box contents Connecting the Water Supply Screw Pack contents Signing off your Shower Control Panel Instructions (Steam Version) Levelling the Tray/Installing the Waste Control Panel Instructions (Shower Cabin Version) Applying RubberGum...
  • Page 3 Last Modified: 20/08/2020 Thank you for your recent purchase of an Insignia shower. Please read this booklet with great care to ensure you get the best out of your build and have a shower that will last for many years to come! Like everything, in order to obtain a first class product that will serve you well for many years, the effort and correctness put into the assembly will reflect in the quality of your finish.
  • Page 4 TIP 4—Sealing When using Insignia’s RubberGum, please ensure the product does not come in contact with your silicone as this will cause the RubberGum to fail and will not adhere as intended. Rubbergum is immediately waterproof and will gain additional strength over time.
  • Page 5 www.insigniarange.com Last Modified: 20/08/2020 Electrical Requirements Pressure/Water Requirements Tools Required STEAM VERSION We recommend a BAR pressure between 2.5 and 3.4 BAR. If You will require: you have a combi boiler system no problem should be Voltage Rating 220-240AC experienced. If you have a gravity feed older type installation •...

  • Page 6: What's In The Boxes

    www.insigniarange.com Last Modified: 20/08/2020 What’s in the Boxes? Contents Quantity Framework Top Rail Bottom Rail Tray Shower Tray Outer fixed uprights Waste + Hose Curved corner posts Glass Shelf Inner upright post Riser Rail for hand shower Magnetic door seal Screw Pack Rear flap door seal Shower hose...
  • Page 7 Drill Piece AK2.5 2.5mm Allen Key VERY IMPORTANT Have you got everything? If not please contact the Insignia Support Line on 01908 226545. Remember NEVER book your tradesman until everything has arrived, been checked and is present. No replacement/missing parts can be obtained free of charge during or after the build.
  • Page 8 www.insigniarange.com Last Modified: 20/08/2020 Step 1 — Level the Tray and Installing the Waste NOTE: MUST DRILL OUT Twist to adjust ON STEAM VERSION ONLY...
  • Page 9 www.insigniarange.com Last Modified: 20/08/2020 Step 2 — Applying RubberGum to the Tray Apply RubberGum to raised sections of the tray and remove backing paper.
  • Page 10 www.insigniarange.com Last Modified: 20/08/2020 Step 3 — Installing the Right Column and Right Side Panel Rear View NB20 x 6 SW9 x 6 If the RubberGum raises the column or panel and DB 9 mis-aligns the pre-drilled holes for connection, use a drill and Drillbit to make new ones.

  • Page 11: Step 4 - Installing The Back Panel

    www.insigniarange.com Last Modified: 20/08/2020 Step 4 — Installing the Back Panel Rear View NB20 x 6 SW9 x 6 If the RubberGum raises the column or panel and DB 9 mis-aligns the pre-drilled holes for connection, use a drill and Drillbit to make new ones.

  • Page 12: Step 5 - Accessories Installation

    www.insigniarange.com Last Modified: 20/08/2020 Step 5 — Accessories Installation Slide cover off Slide cover off...
  • Page 13 www.insigniarange.com Last Modified: 20/08/2020 Step 6 — Installing the Left Column ———————— NB20 x 6 SW9 x 6 DB 9 Rear View If the RubberGum raises the column or panel and mis-aligns the pre-drilled holes for connection, use a drill and Drillbit to make new ones.
  • Page 14 www.insigniarange.com Last Modified: 20/08/2020 Step 7 — Installing the Right Corner Upright to the Right Side Panel Internal View...
  • Page 15 www.insigniarange.com Last Modified: 20/08/2020 Step 7 — Installing the Right Corner Upright to the Right Side Panel Continued ST16 3.5 x3 DB 9 Internal View...
  • Page 16 www.insigniarange.com Last Modified: 20/08/2020 Step 8 — Connecting the Framework Framework securing clips x4 Internal View Wider rail on top Flat end of vertical uprights sit in the tray Narrow rail at the bottom...
  • Page 17 www.insigniarange.com Last Modified: 20/08/2020 Step 9 — Installing the Framework Internal View...
  • Page 18 www.insigniarange.com Last Modified: 20/08/2020 Step 10 — Installing the Framework Continued ST16 4 x3 DB 9 Internal View...
  • Page 19 www.insigniarange.com Last Modified: 20/08/2020 Step 11 — Installing the Left Corner Upright to the Framework Internal View...
  • Page 20 www.insigniarange.com Last Modified: 20/08/2020 Step 11 — Installing the Left Corner Upright to the Framework Continued ST16 4 x3 DB 9 Internal View...
  • Page 21 www.insigniarange.com Last Modified: 20/08/2020 Internal View Step 12 — Installing the Left Side Panel...
  • Page 22 www.insigniarange.com Last Modified: 20/08/2020 Step 12 — Installing the Left Side Panel Continued NB20 x 6 SW9 x 6 ST16 3.5 x3 DB 9 ———————— Rear View If the RubberGum raises PRESS PANELS the column or panel and DOWN FIRMLY mis-aligns the pre-drilled ON TO THE holes for connection,...
  • Page 23 www.insigniarange.com Last Modified: 20/08/2020 Step 13 — Installing the Roof ST10 x5 Rear View...
  • Page 24 www.insigniarange.com Last Modified: 20/08/2020 Step 14 — Installing the Right Front Fixed Glass Place glass onto the bottom rail and slide into the upright ST18 x2 DB 9...
  • Page 25 www.insigniarange.com Last Modified: 20/08/2020 Step 15 — Installing the Right Front Fixed Glass Seals 12mm Seal 7mm Seal 12mm Note: Fit both seals on the inside of the shower...
  • Page 26 www.insigniarange.com Last Modified: 20/08/2020 Step 16 — Installing the Left Front Fixed Glass Place glass onto the bottom rail and slide into the upright ST18 x2 DB 9...
  • Page 27 www.insigniarange.com Last Modified: 20/08/2020 Step 17 — Installing the Right Front Fixed Glass Seals 12mm Seal 7mm Seal 12mm Note: Fit both seals on the inside of the shower...
  • Page 28 www.insigniarange.com Last Modified: 20/08/2020 Step 18 — Installing Door Handles, Seals and Magnets Ensure magnetic Fit flap facing out seals overlap to of the shower ensure they meet...
  • Page 29 www.insigniarange.com Last Modified: 20/08/2020 Step 19 — Installing the Top Door Wheels x 4 Tighten to secure wheels into door runners. DO NOT OVERTIGHTEN Slide cover off Door Step 20 — Installing the Bottom Door Wheels x4 Slide cover off Door Step 21 —...
  • Page 30 www.insigniarange.com Last Modified: 20/08/2020 Step 22 — Valve/Water Connections Right Column Left Column Foot Massager Monsoon Shower Body Jets Body Jets Hand Shower Hand Shower 1x Washer located on the 2x Washers located on back of the valve the back of the valve The columns market Left and Right are...
  • Page 31 www.insigniarange.com Last Modified: 20/08/2020 Step 23 — Touch Control Panel Connections Steam Version Shower Cabin Version Roof Light Power Supply Speaker Antenna Speaker...

  • Page 32: Step 24-Steam Generator Connections

    www.insigniarange.com Last Modified: 20/08/2020 Step 24—Steam Generator Connections (steam version only) The steam generator has 3 connections. Steam Outlet: Connect the white insulated hose to the steam outlet within your shower as shown in image Make sure these are fitted in the correct position as they are only attached for transportation reasons only.
  • Page 33 www.insigniarange.com Last Modified: 20/08/2020 Step 24—Steam Generator Connections Continued (steam version only) Steam Drain: A — Connect the white plastic threaded connector (Image B— Connect the drain hose from the waste underneath the tray (Image Trim the drain hose from the generator to your desired length and connect the hose to (A) (Image 1) and secure in place with a jubilee clip from the screw pack contents...
  • Page 34 www.insigniarange.com Last Modified: 20/08/2020 Step 25—Connecting up the Water Supply The following set up is recommended for the water supply. Left Valve Right Valve The columns market Left and Right are pictured looking from the back of the shower Requires 2 x 15mm equal T-Valves Hot Water Cold Water Supply...
  • Page 35 3. Do not aim the hand shower directly at the joints of your shower as this does not fall under “normal showering conditions”. However, due to Insignia’s unique design of the shower tray, water will only leak back in to the tray so you won’t get flooded.

  • Page 36: Control Panel Instructions

    Press once to turn on the panel. Simply press again to turn it off. When powering down the 03 will automatically start and last for approximately 10 minutes. After this the screen will power off. To see our tutorial videos for operating Insignia control panel’s, please search for “Insignia Showers” on YouTube and find our “Insignia Control Panel”...
  • Page 37 When the Bluetooth is activated this will skip to the next song in your playlist. To see our tutorial videos for operating Insignia control panel’s, please search for “Insignia Showers” on YouTube and find our “Insignia Control Panel” Playlist, or you can...
  • Page 38 www.insigniarange.com Last Modified: 20/08/2020 Bluetooth Connectivity and Radio Tuning Instructions Connecting to Bluetooth Step 2 Step 1 Then simply go on your device and pair To connect a device via up with the shower which should be Bluetooth, press the music shown as “INS”.
  • Page 39 Last Modified: 20/08/2020 Parts List Internal Items Part Code Part Description SP337 Insignia Control Panel (non Part Code Part Description -steam version only) SP063 Monsoon Shower head SP300 Waste hose SP078 Ozone Module (steam version only) SP117 Insignia Control Panel...
  • Page 40 www.insigniarange.com Last Modified: 20/08/2020 Steam Room & Shower Safety Guide Never leave children unattended in the shower or bath. Never bath children (under 12) using whirlpool function if fitted. Regulate the temperature of water before showering. Never allow children to use the steam function. This function is for ADULTS ONLY. Always be aware of the steam outlet position.
  • Page 41 www.insigniarange.com Last Modified: 20/08/2020 Steam Room Usage Guide To use the steam room, turn the control panel on. (1) Press the steam button (2) and your generator will be fed with water and the heating element will begin to heat the water to create steam. (You should be seeing steam from your outlet in approximately 60-90 seconds) To set the temperature you want the cabin to reach, press the function button (3) once the steam is active.
  • Page 42 www.insigniarange.com Last Modified: 20/08/2020 Bathroom Electrical Zones...
  • Page 43 www.insigniarange.com Last Modified: 20/08/2020 There are 3 bathroom electrical zones that have been distinguished in the IEE wiring guidelines and these are: Zone 0 is the area inside a bath, basin or shower. It's characterised as 'any area within a bathroom that can hold water'. Any fitting or electrical appliance utilised inside zone 0 must be a maximum of 12 volts (SELV) and completely secured against both partial and total submersion in water (minimum of IPX7) Zone 1 is the region straight above zone 0 to the height of 2.25m from the base of the bath or shower.
  • Page 44 (EEE) have to fulfil certain obligations. Under the WEEE directive Insignia is considered the producer of certain products we supply and in line with the demands of the legislation we are pleased to offer the op- portunity to return these products to us for treatment and recycling.
  • Page 45 www.insigniarange.com Last Modified: 20/08/2020...
