IMER SMALL 50 Operating, Maintenance, Spare Parts Manual
Mortar mixer
Hide thumbs
Also See for SMALL 50:
- Operating, maintenance, spare parts manual (12 pages) ,
- Operating, maintenance, spare parts manual (75 pages)
Table of Contents
Advertisement
Quick Links
Manuale uso manutenzione ricambi
Manuel utilisation entretien pièces de rechange
Operating, maintenance, spare parts manual
Handbuch für Bedienung, Wartung und Ersatzteile
Manual de uso, mantenimiento y recambios
IMER INTERNATIONAL S.p.A.
53036 POGGIBONSI (SIENA) loc. SALCETO
(ITALY)
tel. 0577 97341 - fax 0577 983304
( 1106045 )
INTONACATRICE
GUNITEUSE
MORTAR MIXER
VERPUTZMASCHINE
ENFOSCADORA
02/2006R1
- Cod. 3225890 -
EL
Advertisement
Table of Contents
Related Manuals for IMER SMALL 50
Summary of Contents for IMER SMALL 50
- Page 1 Manuale uso manutenzione ricambi Manuel utilisation entretien pièces de rechange Operating, maintenance, spare parts manual Handbuch für Bedienung, Wartung und Ersatzteile Manual de uso, mantenimiento y recambios IMER INTERNATIONAL S.p.A. 02/2006R1 53036 POGGIBONSI (SIENA) loc. SALCETO (ITALY) - Cod. 3225890 -...
- Page 2 IMER INTERNATIONAL S.p.A. INTONACATRICI IMER 1) VIBROSETACCIO 1a) SENSORE VIBRO 1b) VIBRATORE 2) COPERCHIOTRAMOGGIA 2a) SENSORE COPERCHIO 3) LANCIA SPRUZZATRICE 4) SCHIACCIA SACCHI 4a) MANOVELLA 4b) RULLO 5) GRIGLIA TRAMOGGIA 6) TRAMOGGIA 7) QUADRO ELETTRICO 8) MOTORIDUTTORE 9) AGITATORE 10) ROTORE - VITE ECCENTRICA -...
- Page 3 IMER INTERNATIONAL S.p.A. TABELLA - TABLEAU - TABLE - TABELLE - TABLA 1 SMALL 50 DATI TECNICI DONNEES TECHNIQUES TECHNICAL DATA TECHNISCHE DATEN DATO TECNICOS 1106045 (115V / 60 Hz) Codice macchina Code machine Machine code Maschinencode Código de la máquina ALIMENTACIÓN PRINCIPAL...
-
Page 4: Technical Data
4.2 DESCRIPTION OF MAIN ACCESSORIES REQUIRED reliability and innovative technical solutions.. FOR THE RANGE OF APPLICATIONS SMALL 50 is undoubtedly the smallest and most versatile pump - WORKING IN SAFETY. . available. There are manifold applications in which this pump To ensure complete safety, read all the instructions in represents the ideal solution in terms of operation and speed. -
Page 5: Electrical Safety
6. ELECTRICAL SAFETY Maintenance: Check the air filters weekly, clean or replace when The SMALL 50 mortar mixer is constructed according to standard EN necessary, above all if working in excessively dusty environments (see compressor operation and maintenance 60204-1, with protection against water sprays and protection against manual). -
Page 6: Mechanical Safety
7. MECHANICAL SAFETY Position the mortar mixer in a suitably ventilated environment The hazardous points on the IMER mortar mixer are protected where it does not constitute an obstruction either during use or by means of suitable safety devices, which must remain fitted... - Page 7 IMER INTERNATIONAL S.p.A. IMER MORTAR MIXERS 11. START-UP (see fig.6) After positioning the machine, prepare a bucket with a quantity of approx. 10l. of grout. Pour the grout into the machine hopper, or, in the case of using colorant products, directly in the machine pipelines before connection.
- Page 8 OVERLOAD AND ELECTRICAL PROTECTIONS To insert the screw in the stator, use the lubricant spray available from IMER. Never use mineral oil or grease for screw assembly - The electric motors are protected against overload by as this may damage the stator. Avoid all types of benzene.
-
Page 9: Maintenance
- Never start up the mortar mixer during repairs. Repairs to the electrical installation must be performed exclusively by specialised personnel. Use exclusively original IMER spare parts; modifications to parts are strictly prohibited. - If any guards are removed for repairs, ensure they... - Page 10 IMER INTERNATIONAL S.p.A. IMER MORTAR MIXERS FAULT CAUSE CORRECTIVE ACTION Machine does not start, Electric current - Check points listed alongside compressor does not start - No current delivered to connector of site panel (fuses)? and the blue light is OFF...
