- Page 1 ORTAL CORNER FIREPLACES: SPECIFICATIONS & PRODUCT GUIDE...
- Page 2 • Always used a licensed gas fitter / plumber to install the appliance IMPORTANT: THIS IS NOT AN INSTALLATION MANUAL. PLEASE REFER TO THE DETAILED INSTALLATION MANUAL DELIVERED WITH THE APPLIANCE. OBLICA | SPECIFICATIONS AND PRODUCT GUIDE PAGE 2...
-
Page 3: Specifications
0.50kPA 0.22kPA 125/205mm 7x1.05mm orifice 250 RS/LS Marked 1400: with single 3.8mm orifice B160 Marked 800: with 52MJ/h 1.13kPA 0.50kPA 0.22kPA 125/205mm 7x1.05mm orifice 250H RS/LS Marked 1400: with single 3.8mm orifice OBLICA | SPECIFICATIONS AND PRODUCT GUIDE PAGE 3... - Page 4 250 RS/LS 2616 2534 x 549 412 x 549 250H RS/LS Note: Minimum height off of the floor for all front facing Ortal fireplaces is 210mm. Appliance legs must not be removed. OBLICA | SPECIFICATIONS AND PRODUCT GUIDE PAGE 4...
- Page 5 200H RS/LS 2170 combustible material and gaps sealed with a non-combustible fire 250 RS/LS 2664 250H RS/LS 2670 proof sealant. We recommend the fireplace to be in position and flued prior to cladding. OBLICA | SPECIFICATIONS AND PRODUCT GUIDE PAGE 5...
- Page 6 We recommend the fireplace to be in position and flued prior to framing/cladding. We recommend using 16mm Gypsum fire rated plasterboard or its equivalent for the enclosure of the fireplace chase. OBLICA | SPECIFICATIONS AND PRODUCT GUIDE PAGE 6...
- Page 7 Heat release vent MODEL (min surface) 60 to 130 0.08m 150 to 200 0.13m 0.16m These are minimum requirements and the surface can be greater if desired. OBLICA | SPECIFICATIONS AND PRODUCT GUIDE PAGE 7...
-
Page 8: Access Panel
The servicing procedure will take longer than through an access panel. Fireplace installers are advised to consult with their clients, project architects or interior designers regarding the advantages and disadvantages of each service option. FIRE ACCESS PANEL OBLICA | SPECIFICATIONS AND PRODUCT GUIDE PAGE 8... -
Page 9: Recessed Installation
7. TV CLEARANCES RECESSED INSTALLATION FLUSH INSTALLATION 305mm MIN 305mm MIN OBLICA | SPECIFICATIONS AND PRODUCT GUIDE PAGE 9... - Page 10 TESTED AND APPROVED BY AGA & IAPMO-R&T FOR USE WITH NATURAL GAS (NG). Australian Standard AS5263-0:2016 - Decorative Gas Log and Other Fuel Effect Appliances Patent Pending for screen barrier glass bracket: USSN 60/040,074 OBLICA | SPECIFICATIONS AND PRODUCT GUIDE PAGE 10...
