Page 1: Table Of Contents
PAXFOCUS INSTALLATION AND USER MANUAL 1. TECHNICAL DATA 2. PRE-INSTALLATION 3. INSTALLATION 4. OPERATION 5. TESTING Keep for future use OBLICA 200 Argyle St Fitzroy VIC 3065 03 9416 0400... -
Page 2: Technical Data
219mm Flue weight 16Kg/meter External flue kit Triple skin 200/250/300mm DETERMINED UNDER TEST CONDITIONS: Nominal thermal output Efficiency 46,1% PAXFOCUS ATTACHED TO NON COMBUSTABLE WALL FLUE ø219 mm FIREBOX ø950 mm OBLICA | PAXFOCUS INSTALLATION AND USER MANUAL PAGE 2... -
Page 3: Pre-Installation
2. PRE-INSTALLATION Congratulations on your purchase of the PaxFocus. This appliance should be installed and checked by a qualified professional. Ensure you have read the operation guidelines thoroughly prior to first use. For any questions or concerns please contact Oblica on 03 9416 0400. - Page 4 Biztonsági távolság gyúlékony For information on heat shielding please contact our anyagoktól. Dro a distance no viegli uzliesmojo iem office on 03 9416 0400 or email info@oblica.com.au. materi liem. Non Combustible Combustible Leistinas saugus atstumas nuo degi med iag .
-
Page 5: Installation
TYPICAL FLAT ROOF INSTALLATION CHINAMAN HAT (Anti-Down-Draft device) TRIPLE SKIN FLUE 200 X 250 X 300 (8’ x 10’ x 12’) RUBBER FLASHING PLASTER CEILING MINIMUM GAP 25mm CEILING FLANGE CONNECTOR LOWER FLUE ø219mm. OBLICA | PAXFOCUS INSTALLATION AND USER MANUAL PAGE 5... - Page 6 PITCHED ROOF INSTALLATION (CUSTOM MADE FLANGE) CHINAMAN HAT (Anti-Down-Draft device) TRIPLE SKIN FLUE 200 X 250 X 300 (8’ x 10’ x 12’) RUBBER FLASHING PLASTER CEILING MINIMUM GAP 25mm CEILING FLANGE CONNECTOR LOWER FLUE ø219mm. OBLICA | PAXFOCUS INSTALLATION AND USER MANUAL PAGE 6...
- Page 7 The top of the flue must be 1200mm above the roofline. Alternatively, there must be a minimum distance of 3 meters from any higher section of roof. > 3 m – > 120 cm – > 120 cm > 120 cm – – OBLICA | PAXFOCUS INSTALLATION AND USER MANUAL PAGE 7...
- Page 8 RRF - 1625 29 07 1313 © atelier dominique imbert, 2013. © atelier dominique imbert, 2013. 3. INSTALLATION (CONTINUED) OBLICA | PAXFOCUS INSTALLATION AND USER MANUAL PAGE 8 - 2 - - 2 -...
- Page 9 3. INSTALLATION paxfocus RRF - 1625 (CONTINUED) 29 07 1313 © atelier dominique imbert, 2013. © atelier dominique imbert, 2013. Needs more ventilation at rear of heater. - 3 - OBLICA | PAXFOCUS INSTALLATION AND USER MANUAL PAGE 9...
- Page 10 FLOOR PROTECTOR LAID ON JOIST WALL WALL FIREBOX FIREBOX 200mm Combustible 200mm Combustible Insulative board (6mm) Insulative board (6mm) floor (eg. timber) floor (eg. timber) + non combustible finish + non combustible finish Joist Joist OBLICA | PAXFOCUS INSTALLATION AND USER MANUAL PAGE 10...
- Page 11 Cement sheet section must be ventilated FIREBOX (Opening on both sides) Floor protector / non combustible finish FIREBOX Floor protector / non combustible finish Combustible floor (eg. timber) Combustible floor (eg. timber) OBLICA | PAXFOCUS INSTALLATION AND USER MANUAL PAGE 11...
-
Page 12: Operation
• The maximum load capacity for the PaxFocus is 20kg of wood. • Burning only seasoned hardwood helps to protect the environment and lower emissions. For details of a wood supplier in your area please call our office on 03 9416 0400 or email info@oblica.com.au. WARNING: •... -
Page 13: Testing
The maximum carbon dioxide output by the appliance during the high burn rate prescribed in AS/NZS 4013:1999 was 3.75%. CONCLUSION: This appliance meets the requirements of AS/NZS 4013:1999 section 1.2.3 (f) and is classified as an excluded appliance. OBLICA | PAXFOCUS INSTALLATION AND USER MANUAL PAGE 13...
