Summary of Contents for Oblica Focus Series

  • Page 1: Table Of Contents

    SLIMFOCUS: MODEL SPECIFICATIONS 1. TECHNICAL DATA 2. PRE-INSTALLATION 3. INSTALLATION 4. OPERATION 5. TESTING Keep for future use...

  • Page 2: Technical Data

    1. TECHNICAL DATA WEIGHT AND DIMENSIONS: Dimensions Firebox O 324mm Firebox weight 180kg Flue kit Standard 6”/8”/10” DETERMINED UNDER TEST CONDITIONS: Nominal thermal output Efficiency (Australian Test) Emissions (Australian Test) 1.4 g/Kg OBLICA | SLIMFOCUS INSTALLATION AND USER MANUAL PAGE 2...

  • Page 3: Pre-Installation

    Congratulations on your purchase of the SlimFocus. This appliance should be installed and checked by a qualified professional. Ensure you have read the operation guidelines thoroughly prior to first use. For any questions or concerns please contact Oblica on 03 9416 0400. The installation process is outlined below: –...
  • Page 4 Non Combustible Australian Building Code. For information on heat shielding please contact our office on 03 9416 0400 or email info@oblica.com.au. Configuration 1 – Parallel installation Combustible 2.2 Clearance from glass 300mm minimum clearance is required from normal 550mm non-combustible glass.

  • Page 5: Installation

    (Anti-Down-Draft device) TRIPLE SKIN FLUE 150 X 200 X 250 (6’ x 8’ x 10’) RUBBER FLASHING Insulative pad CROSS BAR SET IN-BETWEEN RAFTERS (Plaster Ceiling Minimum Gap) CEILING FLANGE SUSPENSION BRACKET OBLICA | SLIMFOCUS INSTALLATION AND USER MANUAL PAGE 5...
  • Page 6 3. INSTALLATION (CONTINUED) PITCHED ROOF INSTALLATION (CUSTOM MADE BRACKET) OBLICA | SLIMFOCUS INSTALLATION AND USER MANUAL PAGE 6...
  • Page 7 3. INSTALLATION (CONTINUED) OBLICA | SLIMFOCUS INSTALLATION AND USER MANUAL PAGE 7...
  • Page 8 3. INSTALLATION (CONTINUED) OBLICA | SLIMFOCUS INSTALLATION AND USER MANUAL PAGE 8...
  • Page 9 Ensure flue is installed as per Australian 8” Outer Case standards (see the following diagrams below). 10” Outer Case RUBBER DEKTITE FLASHING 6” Active Flue 8” Outer Case 10” Outer Case CEILING RING 8” Flue OBLICA | SLIMFOCUS INSTALLATION AND USER MANUAL PAGE 9...
  • Page 10 The top of the flue must be 900mm above the roofline. Alternatively, there must be a minimum distance of 3 meters from any higher section of roof. > 3 m – > 900 cm – > 900 cm > 900 cm – – OBLICA | SLIMFOCUS INSTALLATION AND USER MANUAL PAGE 10...
  • Page 11 Non combustible finish + non combustible finish floor (eg. timber) floor (eg. timber) (eg.tiles) Concrete Joist FLOOR PROTECTOR LAID ON JOIST Combustible Insulative board (9mm) floor (eg. timber) + non combustible finish Joist OBLICA | SLIMFOCUS INSTALLATION AND USER MANUAL PAGE 11...
  • Page 12 300mm 300mm Floor protector Combustible floor (eg: Timber) 300mm 925mm TOP VIEW Minimum floor protector size in a non rotating configuration. 188mm 188mm Floor protector 300mm Combustible floor (eg: Timber) 700mm OBLICA | SLIMFOCUS INSTALLATION AND USER MANUAL PAGE 12...

  • Page 13: Operation

    • The maximum load capacity for the SlimFocus is 10kg of wood. • Burning only seasoned hardwood helps to protect the environment and lower emissions. For details of a wood supplier in your area please call our office on 03 9416 0400 or email info@oblica.com.au. WARNING: •...

  • Page 14: Testing

    55% and a particulate emissions factor of not greater than 2.5g/kg of hardwood thatcomplies to AS/NZS 4014.1 in AS/NZS 4013 (2014). OBLICA | SLIMFOCUS INSTALLATION AND USER MANUAL PAGE 14...
