Summary of Contents for Oblica Tennessee
-
Page 1: Table Of Contents
TENNESSEE: MODEL SPECIFICATIONS 1. TECHNICAL DATA 2. PRE-INSTALLATION 3. INSTALLATION 4. OPERATION 5. TESTING Keep for future use... -
Page 2: Technical Data
Emissions (Australian Test) 0.8 g/Kg WEIGHT AND DIMENSIONS: Dimensions Firebox W780 x H798 x D428mm Firebox weight 170kg DETERMINED UNDER TEST CONDITIONS: Nominal thermal output Efficiency (Australian Test) FLUE Standard 7” OBLICA | TENNESSEE INSTALLATION AND USER MANUAL PAGE 2... -
Page 3: Pre-Installation
2. PRE-INSTALLATION Congratulations on your purchase of the Tennessee. This appliance should be installed and checked by a qualified professional. Ensure you have read the operation guidelines thoroughly prior to first use. For any questions or concerns please contact Oblica on 03 9416 0400. - Page 4 Australian Building Code. Non Combustible Combustib For information on heat shielding please contact our office on 03 9416 0400 or email info@oblica.com.au. 250mm Configuration 1 – Parallel installation Non Combustible Combustible Non Combustible...
-
Page 5: Installation
DEKTITE FLASHING 7” Active Flue 9” Outer Case 11” Outer Case CEILING RING 9” Outer decorative casing 7” Active Flue Crimped end up on dec outer case 9” Outer decorative casing FIREBOX OBLICA | TENNESSEE INSTALLATION AND USER MANUAL PAGE 5... - Page 6 The top of the flue must be 1200mm above the roofline. Alternatively, there must be a minimum distance of 8 meters from any higher section of roof. > 8 m – > 120 cm – > 120 cm > 120 cm – – OBLICA | TENNESSEE INSTALLATION AND USER MANUAL PAGE 6...
- Page 7 Floor protector 90mm Floor protector 200mm 90mm Combustible 200mm Insulative board (6mm) floor (eg. timber) + non combustible finish Combustible Insulative board (6mm) floor (eg. timber) + non combustible finish Joist OBLICA | TENNESSEE INSTALLATION AND USER MANUAL PAGE 7...
- Page 8 Non combustible finish floor (eg. timber) (eg.tiles) Concrete Concrete TOP VIEW 90mm Floor protector 90mm 90mm Floor DOOR protector Combustible floor 200mm (eg: Timber) 300mm 90mm DOOR Combustible floor 200mm (eg: Timber) 300mm OBLICA | TENNESSEE INSTALLATION AND USER MANUAL PAGE 8...
-
Page 9: Operation
• The maximum load capacity for the Tennessee is 10kg of wood. • Burning only seasoned hardwood helps to protect the environment and lower emissions. For details of a wood supplier in your area please call our office on 03 9416 0400 or email info@oblica.com.au. WARNING: •... -
Page 10: Testing
0.8g/kg of dry wood, within the maximum specification of 4.0g/kg of dry wood. CONCLUSION: This appliance does comply with the requirements of AS/NZS 4013:1999 for the configuration tested. OBLICA | TENNESSEE INSTALLATION AND USER MANUAL PAGE 10...
