Page 1: Table Of Contents
Skantherm turn: InStallatIon and uSer manual 1. Technical DaTa 2. PRe-insTallaTion 3. insTallaTion 4. oPeRaTion 5. TesTinG Keep for future use oblIca 200 argyle st Fitzroy Vic 3065 03 9416 0400... -
Page 2: Technical Data
1. technIcal data WeIght and dImenSIonS: Dimensions W1150 x h852 x D382mm Firebox weight 213kg Flue kit standard 6” determIned under teSt condItIonS: nominal thermal output efficiency 78,4% FLUE Standard 6” 1150 oblica | turn InstallatIon and user Manual page 2... -
Page 3: Pre-Installation
Turn. This appliance should be installed and checked by a qualified professional. ensure you have read the operation guidelines thoroughly prior to first use. For any questions or concerns please contact oblica on 03 9416 0400. The installation process is outlined below: –... - Page 4 Building code. Non Combustible Combustible For information on heat shielding please contact our office on 03 9416 0400 or email info@oblica.com.au. configuration 1 – Parallel installation Non Combustible Combustible Non Combustible...
-
Page 5: Installation
DEKTITE FLASHING 6” Active Flue 8” Outer Case 10” Outer Case CEILING RING 8” Outer decorative casing 6” Active Flue Crimped end up on dec outer case 8” Outer decorative casing FIREBOX oblica | turn InstallatIon and user Manual page 5... - Page 6 The top of the flue must be 1200mm above the roofline. alternatively, there must be a minimum distance of 8 meters from any higher section of roof. > 8 m – > 120 cm – > 120 cm > 120 cm – – oblica | turn InstallatIon and user Manual page 6...
- Page 7 Protector laId on JoISt 1200mm 80mm 1200mm 80mm Combustible Insulative board (6mm) floor (eg. timber) + non combustible finish Combustible Insulative board (6mm) floor (eg. timber) + non combustible finish Joist Joist oblica | turn InstallatIon and user Manual page 7...
- Page 8 (eg.tiles) 140mm Combustible Non combustible finish floor (eg. timber) (eg.tiles) Concrete 140mm Concrete 1200mm toP VIeW 80mm 1200mm 80mm Floor protector Combustible floor (eg: Timber) Floor protector Combustible floor (eg: Timber) oblica | turn InstallatIon and user Manual page 8...
-
Page 9: Operation
• The maximum load capacity for the Turn is 10kg of wood. • Burning only seasoned hardwood helps to protect the environment and lower emissions. For details of a wood supplier in your area please call our office on 03 9416 0400 or email info@oblica.com.au. Warning: • Do not use flammable liquids or aerosols to start or rekindle the fire. -
Page 10: Testing
2.9g/kg of dry wood, within the maximum specification of 4.0g/kg of dry wood. concluSIon: This appliance does comply with the requirements of as/nZs 4013:1999 for the configuration tested. oblica | turn InstallatIon and user Manual page 10...
