Ravaglioli KPH 370.42K Translation Of The Original Instructions page 22

Portata/Capacity 4200 kg
KPH370.42 K (Per tutte le installazioni / For all installations)
KPH370.42 LiK (Per tutte le installazioni / For all installations)
KPH370.42 YK (Per tutte le installazioni / For all installations)
22
A
KPH370.42 K
KPH370.42 LiK
KPH370.42 YK
(installazione stretta)
(Narrow installation)
KPH370.42 YK
(installazione standard)
(standard installation)
0484-M004-4
A B
4006 1500
4006 1500
4156 1500
4258 1500
P = kg Mx kgmm
2500 1.900.000
2550 2.350.000
2550 2.450.000
6
1
My kgmm
1.500.000
1.500.000
1.800.000
