C RIPARTIZIONE DEL CARICO
LOAD DISTRIBUTION
GEWICHT VERTEILUNG
REPARTITION DE CHARGE
REPARTICION DE LA CARGA
P1(P2)
P1 P2 Q=P1+P2
C
Q kg kg kg
mm
710 1830 920 2750
800 2100 1050 3150
6
P2(P1)
900 2400 1200 3600
1000 2800 1400 4200
400
5
4
3
2
VEICHLES LIFT
MODEL
Y E A R CAPACITY KG. SERIAL N°
2
PORTATA
1
MAX
1
2
3
4
5
6
6
5
4
3
KPH 370.42LIK
999909520 TARGHeTTA PORTATA 4200 Kg
TARGA MATRiCOLA
99990758 TARGHeTTA PeRiCOLO
999909850 TARGHeTTA isTRUZiONi
999912530 TARGHeTTA 220V 60Hz 1Ph
999912430 TARGHeTTA 230V 60Hz 1Ph
999912520 TARGHeTTA 380V 60Hz 3Ph
999912510 TARGHeTTA 220V 60Hz 3Ph
999912390 TARGHeTTA 230V 50Hz 3Ph
999912380 TARGHeTTA 400V 50Hz 3Ph
999915621 TARGHeTTA RiPARTiZiONe CARiCO (4200 kg) PLATe
