Firing Setting

8.1 Firing Setting with Analog Input Option

The BF firing performed in Digital mode in the Thyristor unit give a lot of advantages because switches Thyristor
at zero voltage crossing (ZC) without EMC interferences. Analog input is necessary for BF and can be decided
how many complete Cycle we want at 50% of power demand.
This value can be 4, 8 or 16 complete Cycles.
35A-45A
CN1
JP4
- +
+
CN2
JP1
JP5
JP4 JP5
60A-90A
K1
K2
G2
Firing Type JP4
BF4 Open
BF8 Close
BF16 Open
24
User's manual
JP4
G1
K1
K2
G2
- +
JP3
JP2
JP6
JP5
Open
Open
Close
JP5
+
JP1
