Technical Specification; General Features; Input Features; Power Output Features - CD Automation CD3000S1PH User Manual

CD3000S
1PH from 10A to 90A
4

Technical Specification

4.1 General features

Cover and Socket material:
Heat-sink:
Delay switch ON time:
Delay switch OFF time:
Auxiliary Voltage:

4.2 Input features

Analog Input:
(Loop Powered)
Logic input SSR:
(Standard)
Logic input SSR:
(low current)
Version with Analog Input Option:
Analog Input:
(Standard)
Analog Input:
Heater Break Alarm (Optional):
Is a microprocessor based circuit to diagnose partial or total load failure and short circuit on SCR and fuses
failure. Discrimination better than 20%. Latching alarm.
Relay Output:

4.3 Power output features

Repetitive peak
Voltage
Size
range
(A) (V) 480V
2x10A 24÷240 1200
(S0)
15A (S0) 24÷480 1200
25A (S0) 24÷480 1200
35A (S3) 24÷600 1200
45A (S3) 24÷600 1200
60A (S7) 24÷600 1200
90A (S7) 24÷600 1200
PolymericV2
Anodized aluminum
0.5 period Max
0.5 period Max
12÷24V dc/ac (max 70mA)
4 - 20mA
(6,5Vdc Min)
4 - 30Vdc 12mA Max
(ON ≥ 4Vdc - OFF < 1Vdc)
5 - 30Vdc 5mA Max
(ON ≥ 5Vdc - OFF < 1Vdc)
0 ÷ 10Vdc (15KΩ)
4 ÷ 20mA (100Ω)
0.5A at 125VAC
Latching
reverse
current
Voltage
600V (mAeff)
1200 150
1200 150
1200 150
1600 250
1600 250
1600 450
1600 450
Max peak Leakage I
one cycle current thyristor
(10ms) (A) (mAeff) tp=10msec
230 15
230 15
230 15
400 15
600 15
1000 15
2000 15
12
User's manual
2
T value Frequency
range
(Hz)
610 47÷70
610 47÷70
610 47÷70
780 47÷70
1800 47÷70
4750 47÷70
19100 47÷70
Power Isolation
loss Voltage
I=Inom
Vac
(W)
20 2500
18 2500
30 2500
42 2500
54 2500
72 2500
108 2500
