CD3000S
1PH from 10A to 90A

4.4 Environmental installation conditions

Ambient temperature
Storage temperature
Installation place
Altitude
Humidity
Pollution Level

4.5 Derating curve

l max = l nominal x K
Derating
For higher cabinet
temperature
contact the producer
of the unit

4.6 Led Status and Alarms

Only with Options Analog Input and/or Heater Break
The following events and alerts don't stop the unit:
• SCR Short circuit (only with the HB option)
• Heater Break (only with the HB option)
When one of these alarms is active, the HB Relay change status.
LED STATUS
ON
SC
HB
1,2
1
0,8
0,6
0,4
0,2
0
15 20
DESCRIPTION
Load IS NOT powered
Load IS powered
SCR OK
SCR Short Circuit
Load OK
Load Fault
0-40°C (32-104°F) at nominal current.
Over 40°C use the derating curve.
-25°C to 70°C, -13°F to 158°F
Don't install at direct sun light,
where there are conductive dust, corrosive gas,
vibration or water and also in salty environmental.
Up to 1000 meter over sea level.
For higher altitude reduce the nominal current
of 2% for each 100m over 1000m
From 5 to 95% without condense and ice
Up to 2nd Level ref. IEC 60947-1 6.1.3.2
1 1 1 1
25 30 35
CABINET TEMPERATURE °C
13
User's manual
1
0,9
0,8
40 45 50 55
