- Page 1 Operating Instructions Pressure sensor with metallic measuring cell VEGABAR 29 Two-wire 4 … 20 mA Document ID: 57087...
-
Page 2: Table Of Contents
VEGA Tools app and DTM (Bluetooth) ................28 10 Diagnostics and servicing ....................30 10.1 Maintenance ........................30 10.2 Rectify faults ........................30 10.3 Diagnosis, fault messages ..................... 31 10.4 Status messages according to NE 107 ................31 VEGABAR 29 • Two-wire 4 … 20 mA... - Page 3 13.5 Trademark ........................52 Safety instructions for Ex areas Take note of the Ex specific safety instructions for Ex applications. These instructions are attached as documents to each instrument with Ex approval and are part of the operating instructions. Editing status: 2021-02-25 VEGABAR 29 • Two-wire 4 … 20 mA...
-
Page 4: About This Document
Symbols used Document ID This symbol on the front page of this instruction refers to the Docu- ment ID. By entering the Document ID on www.vega.com you will reach the document download. Information, note, tip: This symbol indicates helpful additional infor- mation and tips for successful work. -
Page 5: For Your Safety
During work on and with the device, the required personal protective equipment must always be worn. Appropriate use The VEGABAR 29 is a pressure transmitter for process pressure and hydrostatic level measurement. You can find detailed information about the area of application in chapter " Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions. - Page 6 2 For your safety Installations in the US shall comply with the relevant requirements of the National Electrical Code (ANSI/NFPA 70). Installations in Canada shall comply with the relevant requirements of the Canadian Electrical Code. VEGABAR 29 • Two-wire 4 … 20 mA...
-
Page 7: Product Description
The respective scope of delivery results from the order specification. Scope of this operating This operating instructions manual applies to the following instrument instructions versions: • Hardware version from 1.0.0 • Software version from 1.3.0 VEGABAR 29 • Two-wire 4 … 20 mA... - Page 8 Fig. 2: Layout of the type label (example) Order/Serial number Field for approvals Technical data Assignment Bluetooth access code QR code for device documentation Documents and software Move to " www.vega.com" and enter in the search field the serial number of your instrument. VEGABAR 29 • Two-wire 4 … 20 mA...
-
Page 9: Principle Of Operation
Enter serial number manually in the VEGA Tools app (available free of charge in the respective stores) Principle of operation Application area VEGABAR 29 is suitable for applications in virtually all industries. It is used for the measurement of the following pressure types. • Gauge pressure •... - Page 10 The ambient pressure is not compensated and does hence influence the measured value. Seal concept The measuring system is completely welded and thus sealed against the process. The process fitting is sealed against the process by a suitable seal. It must be provided by the customer, depending on the process fitting also included in the scope of delivery, see chapter " Technical data", " Materials and weights". VEGABAR 29 • Two-wire 4 … 20 mA...
-
Page 11: Adjustment
Up to the time of installation, the packages must be left closed and stored according to the orientation and storage markings on the outside. Unless otherwise indicated, the packages must be stored only under the following conditions: Reduced effective range with M12 x 1 plug stainless steel (closed metal housing), see chapter "Technical Data" VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 12: Accessories
Welded sockets are used to connect the devices to the process. adapters Threaded adapters enable simple adaptation of devices with stand- ard threaded fittings, e.g. to process-side hygiene connections. Mounting accessories The suitable mounting accessories for VEGABAR 29 includes si- phons, blocking valves and measuring instrument holders. VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 13: Mounting
Use a suitable connection cable (see chapter " Connecting to power supply") • Tighten the cable gland or plug connector • Lead the connection cable downward in front of the cable entry or plug connector VEGABAR 29 • Two-wire 4 … 20 mA... - Page 14 This applies mainly to outdoor installations, in areas where high humidity is expected (e.g. through cleaning processes) and on cooled or heated vessels. Ventilation and pressure Ventilation and pressure compensation for VEGABAR 29 are provided compensation by an air-permeable, moisture-blocking filter element. Fig. 7: Position of the filter element Filter element For effective ventilation, the filter element must always be free of buildup.
-
Page 15: Process Pressure Measurement
Pipeline Keep the following in mind when setting up the measuring system: In vapours • Connect via a siphon Fig. 10: Measurement setup for process pressure measurement of gases in pipelines VEGABAR 29 Blocking valve Siphon in U or circular form Pipeline VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 16: Level Measurement
Keep the following in mind when setting up the measuring system: • Mount the instrument below the min. level • Do not mount the instrument close to the filling stream or emptying area • Mount the instrument so that it is protected against pressure shocks from the stirrer Fig. 12: Measurement setup for level measurement VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 17: Connecting To Power Supply
ISO 4400 1. Loosen the screw on the rear of the plug connector 2. Remove the plug connector and seal from VEGABAR 29 3. Remove the plug insert from the plug housing VEGABAR 29 • Two-wire 4 … 20 mA... - Page 18 Plug insert Plug seal 7. Snap the plug insert into the plug housing and insert the sensor seal 8. Plug the plug insert with seal to VEGABAR 29 and tighten the screw The electrical connection is finished. ISO 4400 plug with Proceed as follows: hinged cover 1.
- Page 19 9. Tighten the screws on the strain relief and cable entry 10. Hook in the cover and push onto the plug connection, tighten cover screw 11. Plug the plug insert with seal to VEGABAR 29 and tighten the screw VEGABAR 29 • Two-wire 4 … 20 mA...
-
Page 20: Wiring Plan
Voltage supply, signal output/Minus Free Note: Contacts 2 and 3 are internally bridged from delivery status approx. week 17/2021. The negative supply can thus be made either on contact 2 or 3. VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 21: Switch-On Phase
Voltage supply, signal output/Minus Switch-on phase After switching on, the device first carries out a self-check: • Internal check of the electronics • The output signal jumps to the set fault current The current measured value is then output on the signal cable. VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 22: Access Protection
If this document is lost, the emergency device code can be retrieved from your personal contact person after legitimation. The storage and transmission of the device codes is always encrypt- ed (SHA 256 algorithm). VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 23: Storing The Codes In Myvega
" PINs and Codes". This greatly simplifies the use of additional adjust- ment tools, as all Bluetooth access and device codes are automati- cally synchronized when connected to the " myVEGA" account VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 24: Setup With Smartphone/Tablet (Bluetooth)
• Operating system: Android 5.1 or newer • Bluetooth 4.0 LE or newer Download the VEGA Tools app from the " Apple App Store", " Goog- le Play Store" or " Baidu Store" to your smartphone or tablet. Connecting Connecting Start the adjustment app and select the function "... -
Page 25: Sensor Parameter Adjustment
Display", " Diagnosis" and others. The selected menu item, recognisable by the colour change, is dis- played in the right half. Fig. 22: Example of an app view - Setup measured values VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 26: Setup With Pc/Notebook (Bluetooth)
Enter Bluetooth access For authentication, enter in the next menu window the 6-digit code Bluetooth access code: Fig. 23: Enter Bluetooth access code VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 27: Parameter Adjustment
(DTM) according to FDT standard are required. The latest PACTware version as well as all available DTMs are compiled in a DTM Collec- tion. The DTMs can also be integrated into other frame applications according to FDT standard. Fig. 24: Example of a DTM view - Adjustment current output VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 28: Menu Overview
Yes, no pression Offset correction Offset correction (OFS) Execute, automatic correction 0,000 bar Adjustment with medium Apply min. pressure on the sen- Accept 4 mA (LRV) Apply max. pressure on the Accept 20 mA (URV) sensor VEGABAR 29 • Two-wire 4 … 20 mA... - Page 29 Sensor information Device name, serial number, hard- ware version, software version, factory calibration date, Device Re- vision, measuring range begin, measuring range end Sensor features (DTM) Sensor characteristics Features of the instrument version VEGABAR 29 • Two-wire 4 … 20 mA...
-
Page 30: Diagnostics And Servicing
24 hour service hotline Should these measures not be successful, please call in urgent cases the VEGA service hotline under the phone no. +49 1805 858550. The hotline is also available outside normal working hours, seven days a week around the clock. -
Page 31: Diagnosis, Fault Messages
Status messages The status messages are divided into the following categories: • Failure • Function check • Out of specification • Maintenance required and explained by pictographs: Adjustable via VEGA Tools app or PACTware/DTM VEGABAR 29 • Two-wire 4 … 20 mA... - Page 32 Select switching point 1 to greater than ing point 2 switching point 2 Switching points inter- changed F260 Checksum error in the calibration val- Send instrument for repair Error in the calibration VEGABAR 29 • Two-wire 4 … 20 mA...
-
Page 33: Software Update
PC/notebook with PACTware/DTM and Bluetooth USB adapter • Current instrument software as file You can find the current instrument software as well as detailed infor- mation on the procedure in the download area of our homepage. Caution: Instruments with approvals can be bound to certain software versions. Therefore make sure that the approval is still effective after a software update is carried out. VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 34: How To Proceed If A Repair Is Necessary
Attach the completed form and, if need be, also a safety data sheet outside on the packaging • Ask the agency serving you to get the address for the return ship- ment. You can find the agency on our homepage. VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 35: Dismount
11.2 Disposal The device is made of recyclable materials. For this reason, it should be disposed of by a specialist recycling company. Observe the ap- plicable national regulations. VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 36: Certificates And Approvals
NE 21 – Electromagnetic compatibility of equipment • NE 43 – Signal level for fault information from measuring transduc- Exception: Versions with measuring ranges from 250 bar. These are subject of the EU Pressure Device Directive. VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 37: Environment Management System
That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observ- ing the environmental instructions in chapters " Packaging, transport and storage", " Disposal" of these operating instructions. VEGABAR 29 • Two-wire 4 … 20 mA... -
Page 38: Supplement
German silver Ʋ Plug seal Silicone Direct cable outlet Ʋ Cable enclosure PBT/PC, 1.4404 Transmission liquid with measuring ranges up to 100 bar. With measuring ranges from 250 bar dry measuring cell. VEGABAR 29 • Two-wire 4 … 20 mA... - Page 39 -1 … 0 bar/-100 … 0 kPa +4 bar/+400 kPa -1 bar/-100 kPa Absolute pressure 0 … 1 bar/0 … 100 kPa +4 bar/+400 kPa 0 bar abs. Data on overload capability apply for reference temperature. VEGABAR 29 • Two-wire 4 … 20 mA...
- Page 40 0 … +300 psi +1740 psi 0 psi Adjustment ranges Specifications refer to the nominal measuring range, pressure values lower than -1 bar cannot be Zero/Span adjustment: Ʋ Zero -20 … +95 % Ʋ Span -120 … +120 % Maximum permissible Turn Down Unlimited (recommended 20 : 1) VEGABAR 29 • Two-wire 4 … 20 mA...
- Page 41 Damping (63 % of the input variable) 0 … 9 s, adjustable Reference conditions and influencing variables (according to DIN EN 60770-1) Reference conditions according to DIN EN 61298-1 Ʋ Temperature +18 … +30 °C (+64 … +86 °F) Depending on medium and temperature VEGABAR 29 • Two-wire 4 … 20 mA...
- Page 42 Long-term drift zero signal and output span One year < 0.1 % x TD Two years < 0.15 % x TD Five years < 0.2 % x TD 0 … +100 °C (+32 … +212 °F) VEGABAR 29 • Two-wire 4 … 20 mA...
- Page 43 Temperature derating 70 °C (158 °F) 40 °C (104 °F) 0 °C (32 °F) 110 °C 130 °C (230 °F) (266 °F) Fig. 28: Temperature derating VEGABAR 29 Process temperature Ambient temperature VEGABAR 29 • Two-wire 4 … 20 mA...
- Page 44 0 °C (32 °F) 90 °C 100 °C (194 °F) (212 °F) Fig. 29: Temperature derating VEGABAR 29, with activated Bluetooth communication Process temperature Ambient temperature SIP process temperature Device configuration suitable for vapour, i.e. measuring cell seal EPDM or FFKM (Perlast G74S), previous CIP cleaning up to max. +80 °C (+176 °F): Vapour stratification up to Ʋ...
- Page 45 Ʋ for U 24 V DC (18 V < U < 35 V) ≤ 1.0 V (16 … 400 Hz) Load resistor Ʋ Calculation )/0.022 A Depending on the local conditions; with M12 x 1 plug stainless steel (closed full metal housing) effective range up to approx. 5 m (16.40 ft) VEGABAR 29 • Two-wire 4 … 20 mA...
- Page 46 Type 4X Plug according to ISO 4400 with IDC method of termination Direct cable outlet IP66/IP68 (0.5 bar) Type 6P Altitude above sea level 5000 m (16404 ft) Protection class Pollution degree VEGABAR 29 • Two-wire 4 … 20 mA...
-
Page 47: Dimensions
ø 36 mm ø 36 mm (1.42") (1.42") (1.42") Fig. 30: Connection technology VEGABAR 29 M12 x 1 plug connector Plug connector according to ISO 4400 Plug connector according to ISO 4400 with hinged cover Direct cable outlet VEGABAR 29 • Two-wire 4 … 20 mA... - Page 48 ø 5 mm ø 3 mm ( 0.20 ") ( 0.12 ") Fig. 31: VEGABAR 29, threaded fitting not front-flush DU Thread G½ (EN 837), manometer connection C2 Thread M20 x 1.5 (EN 837), manometer connection LF Thread ½ NPT, inside ¼ NPT (ASME B1.20.1) LY Thread ½ NPT (ASME B1.20.1) TI Thread ¼ NPT (ASME B1.20.1) TJ Thread G¼ (ISO 228-1) VEGABAR 29 • Two-wire 4 … 20 mA...
- Page 49 ø 55 mm ( 2.17 ") ( 2.17 ") Fig. 32: VEGABAR 29, threaded fitting front-flush LU Thread G½ (ISO 228-1) N9 Thread G¾ (DIN 3852-E) C5 Thread G1 (ISO 228-1) DA Thread G1½ (DIN 3852-A) C9 Thread 1½ NPT (ASME B1.20.1) VEGABAR 29 • Two-wire 4 … 20 mA...
- Page 50 SW 41 mm (1.61") (1.61") ø 40 mm ø 40 mm ( 1.57 ") ( 1.57 ") Fig. 33: VEGABAR 29, cone/extension fitting DH Thread G1 (ISO 228-1), cone 40° LX Thread G1 (ISO 228-1), hygienic design VEGABAR 29 • Two-wire 4 … 20 mA...
- Page 51 FB SMS DN 51 PN 6 E7 Ingold connection PN 10 FR Varivent N50-40 PN 25 EZ Collar socket DN 40 PN 40 (DIN 11851) E2 Collar socket DN 40 PN 40 (DIN 11864-1, Form A) VEGABAR 29 • Two-wire 4 … 20 mA...
-
Page 52: Industrial Property Rights
Les lignes de produits VEGA sont globalement protégées par des droits de propriété intellec- tuelle. Pour plus d'informations, on pourra se référer au site www.vega.com. VEGA lineas de productos están protegidas por los derechos en el campo de la propiedad indus- trial. Para mayor información revise la pagina web www.vega.com. - Page 53 Notes VEGABAR 29 • Two-wire 4 … 20 mA...
- Page 54 Notes VEGABAR 29 • Two-wire 4 … 20 mA...
- Page 55 Notes VEGABAR 29 • Two-wire 4 … 20 mA...
- Page 56 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2021 VEGA Grieshaber KG Am Hohenstein 113 Phone +49 7836 50-0 77761 Schiltach E-mail: info.de@vega.com...
