Summary of Contents for URC Total Control HDA-IO
- Page 1 HDA-IO Total Control Owner’s Manual HDA-IO Owner’s Manual...
-
Page 2: Table Of Contents
Main: 914-835-4484 techsupport@urc-automation.com For questions on how this device operates contact your certified URC Integrator or URC’s Technical Support Team! H o u r s : 9 : 0 0 a m - 6 p m E S T M - F... -
Page 3: Overview
Overview URC’s HDA-IO Stream Receiver/Injector creates or receives HDA audio streams over the network. This device must be configured by a certified URC integrator to function as either a Stream Injector or Stream Receiver. As a Stream Injector, this device distributes any connected audio source (digital or analog) over the network to any available HDA controlled zone. -
Page 4: Parts & Pieces
HDA-IO Total Control Owner’s Manual Parts & Pieces Included with the HDA-IO is the following:... -
Page 5: Front Panel Descriptions
HDA-IO Total Control Owner’s Manual Front Panel Descriptions There are three (3) LEDs on the front panel of the HDA-IO: 1. Power LED: Indicates one (1) of the following: 2. Status LED: Indicates one (1) of the following: • Solid Blue: Power has been applied to the device and it has •... - Page 6 HDA-IO Total Control Owner’s Manual 3. Ethernet LED: Indicates one (1) of the following: 4. Reset Button: There are two (2) ways to press this button: • Solid Blue: The device has received an IP address from the local network. •...
-
Page 7: Rear Panel Description - Using As A Stream Injector
HDA-IO Total Control Owner’s Manual Rear Panel Description - Using as a Stream Injector Below are the available connections on the rear of the HDA-IO: 1. DC IN: Connect the supplied 12VDC adapter to this port to power the 4. Analog/Digital Inputs: Both of the following inputs can be used HDA-IO. -
Page 8: Rear Panel Description - Using As A Stream Receiver
HDA-IO Total Control Owner’s Manual Rear Panel Description - Using as a Stream Receiver Below are the available connections on the rear of the HDA-IO: 1. DC IN: Connect the supplied 12VDC adapter to this port to power the 4. Analog/Digital Outputs: Only one (1) of the three (3) available outputs can be HDA-IO. -
Page 9: Installation Instructions
HDA-IO Total Control Owner’s Manual Installation Instructions The HDA-IO amplifier is supplied with two (2) “L” shaped brackets for mounting on the wall or secure vertical surface. 1. Insert the supplied screws into the two (2) keyed slots on the L shaped bracket (as displayed on the image at the right). - Page 10 HDA-IO Total Control Owner’s Manual 3. Assure that all screws have been installed securely.
-
Page 11: Network Setup
HDA-IO Total Control Owner’s Manual Network Setup When using more than one (1) HDA devices, URC’s HDA-SW5 Network Switch is REQUIRED on the local network. For more information of the HDA-SW5 Network Switch, please refer to the HDA-SW5 Owner’s Manual. -
Page 12: Hda Modules
Total Control Owner’s Manual HDA Modules URC’s HDA line of products contains several two-way modules that are accessible from any graphical user interface. These modules serve a variety of residential and commercial applications providing end-users with advanced functionality directly from any URC interface. -
Page 13: Specifications
HDA-IO Total Control Owner’s Manual Specifications Audio: • 96 kHz / 24-bit streaming General: • Dolby Digital® and DTS® 5.1 channel Downmixing (digital inputs only) Audio Inputs: • Ducking input capability • 1 Stereo Analog RCA style input • Page event support •... -
Page 14: Safety Precautions
HDA-IO Total Control Owner’s Manual CA U T I O N Risk of electric shock do not open To reduce the risk of CA U T I O N electrical shock, do not remove cover (or back). No user-serviceable parts inside. Refer service to a qualified To prevent electrical shock, service professional... -
Page 15: Important Safety Instructions
HDA-IO Total Control Owner’s Manual Important Safety Instructions • Read Instructions: All the safety and operating instructions should be read • Protect the power cord from being walked on or pinched particularly at plugs, before the apparatus is operated. convenience receptacles, and the point where they exit from the apparatus. •... -
Page 16: Federal Communications Commission
HDA-IO Total Control Owner’s Manual Federal Communications Commission FCC Caution This device complies with Part 15 of the FCC Rules. Operation is subject to the following Interference Statement two conditions: (1) this device may not cause harmful interference, and (2) this device This equipment has been tested and found to comply with the limits for a Class B digital must accept any interference received, including interference that may cause undesired device, pursuant to part 15 of the FCC Rules. -
Page 17: Limited Warranty Statement
WITHOUT IN ANY WAY LIMITING THE GENERALITY OF THE OTHER PROVISIONS HEREIN, THIS LIMITED WARRANTY DOES NOT COVER: (I) URC warrants that at the time of purchase the URC equipment and the URC DAMAGE FROM MISUSE, NEGLECT OR ACTS OF NATURE, (II) - Page 18 URC equipment sold by unauthorized resellers. In the event of any warranty claim, URC will, at its sole option, repair the With the exception of URC’s IR-only, broad-based consumer remotes, none of URC equipment using new or comparable rebuilt parts, or exchange the URC URC’s PC programmable remotes or any of our Total Control®...
-
Page 19: Dolby Audio
PERMITTED BY APPLICABLE LAW. End User Agreement The terms and conditions of the End User Agreement are available at: URC SHALL NOT BE HELD RESPONSIBLE FOR THE STATEMENTS MADE BY OTHERS. https://www.urc-automation.com/legal/end-user-agreement/ SOME STATES OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR...
