PhoXi 3D Scanner M
Quick Start Guide
Scope of Delivery
PhoXi 3D Scanner M
■
Desktop PoE injector (input: 90 ~ 264 VAC, output: 33.6 W, 56 V PoE, IEEE802.3at)
■
M12-X (m) RJ45 (m) ethernet cable
■
Ethernet cable (2x RJ45 (m))
■
Operation of the Scanner
The scanner is operated by the PhoXi Control application. PhoXi Control allows the user to
control the scanner either manually through a graphical user interface or programmatically
through the provided API.
All PhoXi Control resources can be found on the following link:
www.photoneo.com/3d-scanning-software/
Read the complete PhoXi 3D Scanner Manual for more details:
www.photoneo.com/kb/scanner
08/2020
PhoXi 3D Scanner M - Quick Start Guide
1/8
Advertisement
Table of Contents
Related Manuals for Photoneo PhoXi 3D Scanner M
Summary of Contents for Photoneo PhoXi 3D Scanner M
- Page 1 API. All PhoXi Control resources can be found on the following link: www.photoneo.com/3d-scanning-software/ Read the complete PhoXi 3D Scanner Manual for more details: www.photoneo.com/kb/scanner 08/2020 PhoXi 3D Scanner M - Quick Start Guide 1/8 ...
- Page 2 950 g 3D point throughput 16 Million points per second These parameters are valid at 22 °C - 25 °C, at focus distance for white objects with 80 % albedo. 08/2020 PhoXi 3D Scanner M - Quick Start Guide 2/8 ...
- Page 3 Scanning Volume - Model M 08/2020 PhoXi 3D Scanner M - Quick Start Guide 3/8 ...
-
Page 4: Mounting The Scanner
Separate the scanner from high-voltage devices and devices generating high electrical ■ noise. The complete environment conditions for installation can be found in the full user manual at www.photoneo.com/kb/scanner 08/2020 PhoXi 3D Scanner M - Quick Start Guide 4/8 ... -
Page 5: Connecting To The Scanner
- 4 Yellow OPTO_IN1 - 5 Grey OPTO_IN1_GND - 6 Pink OPTO_OUT - 7 Blue OPTO_OUT_GND ground 8 Red OPTO_IN2 *laser interlock signal * laser interlock requires special firmware package 08/2020 PhoXi 3D Scanner M - Quick Start Guide 5/8 ... -
Page 6: Status Leds
Status LEDs The LEDs indicate the following states of the scanner: Supported Network Topologies 08/2020 PhoXi 3D Scanner M - Quick Start Guide 6/8 ... -
Page 7: Powering Requirements
Old PhoXi 3D Scanner cabling compatibility accessories ■ Please contact your sales representative for inquiries about the available options. ■ Warranty Warranty conditions are stated in General Term and Conditions on Photoneo website: www.photoneo.com/kb/terms-conditions 08/2020 PhoXi 3D Scanner M - Quick Start Guide 7/8 ... - Page 8 Laser protective eyewear is normally not necessary. Contact Us Headquarters Web www.photoneo.com Photoneo s.r.o. Support Plynarenska 1 support@photoneo.com 82109 Bratislava Business Inquiries Slovakia sales@photoneo.com 08/2020 PhoXi 3D Scanner M - Quick Start Guide 8/8 ...
