PhoXi 3D Scanner XS
Quick Start Guide
Scope of Delivery
PhoXi 3D Scanner XS
■
Power adapter (90 - 264 VAC / 12 VDC, 60 W) (1)
■
Power cable (2)
■
Ethernet cable adapter (3)
■
L-shaped mounting plate
■

Operation of the Scanner
The scanner is operated by the PhoXi Control application. PhoXi Control allows the user to
control the scanner either manually through a graphical user interface or programmatically
through the provided API.
All PhoXi Control resources can be found on the following link:
www.photoneo.com/3d-scanning-software/
Read the complete PhoXi 3D Scanner Manual for more details:
www.photoneo.com/support
01/2020




PhoXi 3D Scanner XS - Quick Start Guide

1/8
