Freedom9 freeConnect Smart G2420 Specifications

freeConnect Smart
24-port Web Smart Gigabit
with 2 ports Combo-SFP
Networking Switch
freeConnect Smart G2420 > 24-port Web Smart
Gigabit with 2 ports Combo-SFP switch
Networking switch: Affordable - manageable
The freeConnect Smart G2420 offers network manageability and high
throughput at an affordable price. Designed for deployment in high
traffic environments, the 24 gigabit ports provide ample bandwidth
for the most demanding servers and switches. It also comes with 2
Gigabit mini GBIC (Auto-Sense) ports, which allow you to easily
extend distance.
The freeConnect Smart G2420 supports quality of service (QoS) which
gives latency-sensitive traffic such as multimedia, video conferencing,
and VoIP higher priority over standard traffic. The switch also supports
VLANs for network segmentation and port trunking for increased
bandwidth between switches.
Specifications
Standards
Ports
Transfer Rate
Power
Power Consumption
Network Cables
Filtering Address Table
Switching Fabric
Dimensions (w x h x d)
Temperature
Humidity
EMI
Model Numbers
Model Name
Description
Part Number
Revision 2.0 Specifications are subject to change without notice. Copyright 2007 Freedom9 Inc.
G2420
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3x full-duplex flow control
IEEE 802.3z 1000BASE-SX/LX (GBIC)
24 x RJ-45 Auto-MDIX ports, 2 SFP/mini GBIC ports
(shared with 2 RJ45 ports)
Ethernet 10Mbps/20Mbps Full-duplex
Fast Ethernet 100Mbps/200Mbps full-duplex
Gigabit Ethernet 2000Mbps full-duplex
100-240 VAC, 50/60 Hz
35W (Max.)
Ethernet - Cat 3, 4, 5, 6 UTP
Fast Ethernet - Cat 5, 6 UTP
Gigabit Ethernet - Cat 5e, 6 UTP
8K entries
Wire-speed non-blocking, 48 Gbps backplane
17.3" x 1.7" x 8.3" (440 x 44 x 210 mm)
Operating 32°F - 104°F (0°C - 40°C)
Storage 14°F - 158°F (-10°C - 70°C)
Operating 10% - 90% RH
Storage 5% - 90% RH
FCC Class A/CE Mark A/VCCI-A
freeConnect Smart G2420
24-port Gigabit Web Smart Switch
SG2420
Features:
• 24 10/100/1000Mbps Auto-Negotiation
Ethernet ports
• 2 10/100/1000Mbps copper/SFP, shared
with 2 RJ45 ports
• Supports Auto-MDI/MDIX for each port
• Supports Full/Half-Duplex transfer mode
for 10 and 100Mbps
• Full wire speed reception and transmission
• Web-based management
• Port-based VLAN
• Port-based QoS
• Port Trunking and Mirroring
www.freedom9.com
1-888-998-9189
