RUSTA ADVANCED Manual page 68

Step 8 – Mat Assembly
ENG SE NO
The complete trampoline SPRING lay out should look as shown below.
8
NOTE! There are two
lengths of spring.
They must be fitted
according to the
illustration. /
OBS! Det finns två
längder på fjädrarna,
Place the Trampoline Mat (# 18) in the center of the trampoline frame with the warning labels facing up. Begin by de ska monteras
attaching Springs (# 17A and #17B) to the four corners of the mat as shown in FIGURE 16-A, then continue to
enligt illustrationen. /
attach springs in the sequence shown in FIGURES 16-B, 16-C and 16-D.
OBS! Fjærene har
Hint: The number of triangle-rings sewn onto the mat is equal to the number of holes on the frame. If you notice
to lengder og skal
that you have missed a corresponding hole or triangle-ring, remove and reinstall the springs as necessary while
monteres som vist på
maintaining an even distribution of tension of the mat. Make sure to wear gloves and goggles to avoid injuries
/
illustrasjonen.
during assembly.
HINWEIS! Es gibt
zwei Federlängen, die
wie unten abgebildet
montiert werden. /
HUOMIO! Jousia on
kahden pituisia. Ne
tulee asentaa kuvan
mukaisesti.
DE FI
TRAMPOLINE MAT ASSEMBLY
23
FIGURE16-A
