Summary of Contents for Matrix ENDURANCE TOUCH XL
-
Page 3: Important Precautions
IMPORTANT PRECAUTIONS SAVE THESE INSTRUCTIONS DANGER! When using a treadmill, basic precautions should always be followed, including the TO REDUCE THE RISK OF ELECTRICAL SHOCK: following: To ensure your safety and protect the equipment, read all instructions before operating. It is the responsibility of the owner to ensure that all users of Always unplug the equipment from the electrical outlet immediately after using, this equipment are adequately informed of all warnings and precautions. -
Page 4: Power Requirements
If the user does systems, or any other item should lose power when you perform this test. not follow these grounding instructions, the user could void the MATRIX limited warranty. Non-looped (isolated) neutral/grounding means that each circuit must have an individual... - Page 5 ASSEMBLY DANGER! UNPACKING TOOLS REQUIRED: Unpack the equipment where you will be using it. Place the carton F 8mm T-Wrench Improper connection of the equipment- on a level flat surface. It is recommended that you place a protective grounding conductor can result in a risk of F 5mm Allen Wrench covering on your floor.
- Page 6 Torque Value Hardware 77 Nm / 57 ft-lb Bolt Flat Washer MCB Communication Extension Power Wire Ethernet Coax Ground Wire Hardware Torque Value 40 Nm / 29 ft-lb Bolt Spring Washer Flat Washer...
- Page 7 Torque Value Torque Value Hardware Hardware F - 16 Nm / 12 ft-lb H - 40 Nm / 29 ft-lb 30 Nm / 22 ft-lb Bolt Bolt MCB Communication Flat Washer Flat Washer Extension Power Wire Screw Ethernet Coax Ground Wire Emergency Stop TV Power Console Connect Wires...
-
Page 8: Before You Begin
BEFORE YOU BEGIN WARNING! Our equipment is heavy, use care and additional help if necessary when moving. Failure to follow these instructions could result in injury. LOCATION OF THE UNIT Ensure that there is a clear zone behind the treadmill that is at least the width of the treadmill and at least 2 meters (at tRAINING AREA least 79”) long. -
Page 9: Tensioning The Running Belt
Electrical Requirements 20 A dedicated circuit required-non-looped-grounded * Ensure a minimum clearance width of 0.6 meters (24”) for access to and passage around MATRIX equipment. Please note, 0.91 meters (36”) is the ADA recommended clearance width for individuals in wheelchairs. -
Page 10: Intended Use
INTENDED USE CAUTION! RISK OF INJURY TO PERSONS • Treadmill is intended for walking, jogging, or running exercises only. While you are preparing to use the treadmill, do not stand on the belt. Place your feet on the • Always wear athletic shoes while using this equipment. side rails before starting the treadmill. -
Page 11: Maintenance
WARNING: Do not plug the treadmill in until the motor cover has 5) Ensure that any person(s) making adjustments or performing maintenance been reinstalled. or repair of any kind is qualified to do so. MATRIX dealers will provide service and maintenance training at our corporate facility upon request. WARNING! To remove power from the unit, the power cord must be disconnected from the wall outlet. - Page 12 © 2020 Johnson Health Tech Rev 1.0 A...
