Summary of Contents for Matrix TOUCH XL
-
Page 2: Important Precautions
IMPORTANT PRECAUTIONS SAVE THESE INSTRUCTIONS When using Matrix exercise equipment, basic precautions should always be followed, including the following: Read all instructions before using this equipment. It is the responsibility of the owner to ensure that all users of this equipment are adequately informed of all warnings and precautions. -
Page 3: Power Requirements
Additional power requirements are not needed for the add-on digital TV. For units with an integrated TV (like the TOUCH and TOUCH XL), the TV power requirements An RG6 coaxial cable with ‘F Type’ compression fittings will need to be are included in the unit. -
Page 4: Important Notes
ENGLISH ASSEMBLY UNPACKING TOOLS REQUIRED: Unpack the equipment where you will be using it. Place the carton F 8mm T-Wrench on a level flat surface. It is recommended that you place a protective F 5mm Allen Wrench covering on your floor. Never open box when it is on its side. F 6mm Allen Wrench F Phillips Screwdriver IMPORTANT NOTES... - Page 5 ENGLISH ASSEMBLY Torque Value Do not tighten bolts Hardware 77 Nm / 57 ft-lb until step 5 is complete. Bolt Flat Washer MCB Communication Extension Power Wire Ethernet Coax Ground Wire Hardware Do not tighten bolts Torque Value until step 5 is complete. 40 Nm / 29 ft-lb Bolt Spring Washer...
- Page 6 ENGLISH ASSEMBLY Torque Value Hardware H - 40 Nm / 29 ft-lb Bolt Torque Value Tighten all bolts from Hardware Flat Washer F - 16 Nm / 12 ft-lb steps 2–3. MCB Communication Screw 30 Nm / 22 ft-lb Extension Power Wire Bolt Ethernet Flat Washer...
-
Page 7: Before You Begin
ENGLISH BEFORE YOU BEGIN WARNING! Our equipment is heavy, use care and additional help if necessary when moving. Failure to follow these instructions could result in injury. LOCATION OF THE UNIT Ensure that there is a clear zone behind the treadmill that is at least the width of the treadmill and at least 2 meters (at tRAINING AREA least 79”) long. -
Page 8: Tensioning The Running Belt
83.9” x 34.3” x 66.5” 83.9” x 34.3” x 64.2” * Ensure a minimum clearance width of 0.6 meters (24”) for access to and passage around MATRIX equipment. Please note, 0.91 meters (36”) is the ADA recommended clearance width for individuals in wheelchairs. -
Page 9: Intended Use
ENGLISH BEFORE YOU BEGIN INTENDED USE CAUTION! RISK OF INJURY TO PERSONS • Treadmill is intended for walking, jogging, or running exercises only. While you are preparing to use the treadmill, do not stand on the belt. Place your feet on the side •... -
Page 10: Maintenance Schedule
5) Ensure that any person(s) making adjustments or performing maintenance or Unplug the treadmill and remove the motor cover. Check for repair of any kind is qualified to do so. MATRIX dealers will provide service debris and clean with a dry cloth or small vacuum nozzle. - Page 11 © 2021 Johnson Health Tech Rev 1.3 A...
