Stamina Active Aging EasyDecompress Owner's Manual page 9

ASSEMBLY INSTRUCTIONS
STEP 3
Insert the HANDLEBARS(4) into the HANDLEBAR CONNECTOR(23) and secure with CARRIAGE
BOLTS(M8x1.25x37mm)(30) and NYLOCK NUTS(M8x1.25)(15).
STEP 4
Insert the RIGHT HANDRAIL(69) into the MAIN FRAME(1) and secure with CARRIAGE BOLTS
(M8x1.25x37mm)(30) and NYLOCK NUTS(M8x1.25)(15). Repeat on other side.
STEP 5
Slide the PILLOW(26) onto the CUSHION(27) and secure in position with the elastic band. Attach the
CUSHION(27) to the MAIN FRAME(1) with BUTTON HEAD BOLTS(M6x1x15mm)(41).
15
4
26
41
15
69
30
27
1
23
41
30
9
4
15
30
11
15
30
