6.11.
Pressure throttling
Warning:
Throttling the pressure in the hydraulic system is set at the factory. Adjustment should
be made only in justified cases.
The pressure in the hydraulic system can be throttled by a throttle valve (at hydraulic distributor).
A
2
1
A
Throttling valve
1
Loosen the lock nut
2
To throttle the pressure, turn the valve to the right
PIC.6.9 THROTTLING VALVE
33
