ELGO-PLUS SpringerMAX-PRO Instruction page 29

Mini digger

Advertisement

A
Hydraulic pressure controler
6.6. Tracks tension regulation
Warning:
Do not use the mini digger when her tracks are too much or too little strained. Doing
so may destroy them. Tracks tension should be checked every time before working
In case of too low tracks tension it is necessary to adjust it by using the adjustment screws on both
sides of the mini digger. To tension rubber tracks, first loosen support screws on sides of bracket (A),
than regulate the tension by regulation screws (B).
PIC.6.5 HYDRAULIC PRESSURE CONTROL
28
A
