Jib position steering ( E, Pic.4.1)
3
Hydraulic hammer starting ( F, PIC.4.1)
N
1
5. USAGE
5.1. Before working
1
N - neutral position (jib and bucket stay in
neutral position)
1 - jib lowering
2 - jib lifting
N
4
3 – bucket closing
4
4 – bucket opening
2
1 - moving the lever to the left activates the hydraulic hammer
N - neutral position - (jib and bucket stay in neutral position)
