ELGO-PLUS SpringerMAX-PRO Instruction page 14

Left track steering ( A, Pic.4.1)
1 1 - forward – in order to move track forward, push steering lever forward (A,
Pic.4.1)
N - neutral – track stops (the lever returns to this position automatically)
N
2 - backward – in order to move track backwards push steering lever backwards
(A, Pic.4.1)
2
Right track steering ( B, Rys.4.1)
1 - forward – in order to move track forward, push steering lever forward (B,
1
Pic.4.1)
N - neutral – track stops (the lever returns to this position automatically)
N
2 - backward – in order to move track backwards push steering lever backwards
(B, Pic.4.1)
2
Moving forward
Push forward both steering levers (A and B, Pic.4.1), machine will go forward.
Moving backward
Pull back both steering levers (A and B, Pic.4.1), machine will go backward.
Turning left
Push forward the right steering lever (B, Pic.4.1), the right track starts to move forward, the machine
will go forward turning left.
Or:
Pull back left steering lever (A, Pic.4.1) the left track starts to move backward, the machine will go
back turning to the left.
13
