Specifications

7
PowerPad8S
Input Voltage:
Input Current:
Input Connection:
Output Voltage:
Output Current:
Output Power:
Output Power (Total):
Power Supply
Input Voltage:
Input Current:
Input Frequency:
Input Connector:
Output Voltage:
Output Current:
Output Power:
Output Connector:

Certifications

8
• Independently safety tested by the Underwriters
Laboratory (UL) under file #E346549
• CE Tested and marked
• CB Certificate
• FCC Part 15 Tested and marked
• RoHS Compliant

Safety Guidelines and Precautions

9
Please read and understand these
guidelines prior to installation or use.
The PowerPad8S has ESD, over-voltage, over-
current and over-temperature protection. However,
to use the equipment safely you should follow all
local regulations relating to the use of electrical
equipment and note that:
PowerPad8S USER GUIDE
12Vdc
15A
4-pin DIN
5.2V
2.1A Max per Port
10W Max per Port
87.36W Maximum
100-250Vdc
1.8A @ 115 Vac
50-60Hz
C14
12Vdc
8A
96W
4-pin DIN
Input/Output Connectors: 9 x USB Type-A,
Ambient Operating
Temperature Range:
Relative humidity:
Dimensions (approx.):
Approximate weight:
• China CCC certification
• Japanese PSE certification (pending)
• Complies with the latest EN60950 safety
requirements for ITE
• Housed within a UL94-V0 specification fire
enclosure
• Failure to install and operate the equipment
in accordance with all local and these safety
guidelines may result in unit failure, electrical
shock and personal injury.
• The plug on the power cord is considered the
"disconnect device" and consequently the mains
outlet should be located near the hub, easily
accessible in case the power supply needs to be
isolated from the mains power.
• If there is a liquid spillage over a ventilation
slot, external data/power connector or product
aperture, remove power from the unit without
contacting the liquid immediately.
1 x 4-pin DIN
0 ~ 35°C
5% to 95%
non-condensing
198.4 long x 73 wide
x 40 high mm
1.6 kg (inc PSU)
