Type A: Full Black
Type C: Half Black
General
HTW-HT03 series Wifi thermostat is widely used in these environment like Homes, Residential buildings,
Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in
Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.
Features
17 Mainstreaming Languages synchronize in APP(
Italian, Japanese, French, Poland, simplified Chinese, traditional Chinese, Holland, Portuguese, Vietnamese, Arabic, Korean
Snap-In Easy Installation
Fit for EU & Standard Junction Electric Box
Easily Work with Amazon Alexa, Google Assistant, IFTTT
Group Control in 1 App
Consise Design
Ordering Guide
Ordering Information
HTW-HT03- **
e.g. HTW-HT03-3A refers to application:Water Heating, 3A, NC+NO+Com output terminals
-3A
Smart Wifi Thermostat
Code
-3A
Water Heating, 3A, NC+NO+Com output terminals
-16A
Electric Underfloor Heating, 16A, L+N line voltage output terminals
-NV
Water/Gas Boiler, 3A, 1 pair of Non-Voltage output terminals
English, Spanish, Russian, Hungarian, Turkey, Hebrew, German,
Smart Wifi Thermostat
Application
-16A
- 1 -
Reference No.:HTW-HT03 Series
Type B: Half White
Type D: Full White
-NV
Version 2018-1.0
)
Advertisement
Related Manuals for HOTOWELL HTW-HT03 Series
Summary of Contents for HOTOWELL HTW-HT03 Series
- Page 1 Type D: Full White General HTW-HT03 series Wifi thermostat is widely used in these environment like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.
- Page 2 Smart Wifi Thermostat Reference No.:HTW-HT03 Series Specification Power Supply 95~240Vac, 50/60Hz Sensor NTC3950, 10K Current Load 3A(-3A, -NV application) Temperature Accuracy ±0.5°C or ±1℉ Set-Point Range 16A(-16A application) 5~35°C Storage Temp. -5 ~ 45 °C Display Temp. Range 5 ~ 99°C Power Consumption <...
- Page 3 Smart Wifi Thermostat Reference No.:HTW-HT03 Series Operation Buttons/Functions Operation Switch thermostat power On or Off Increase or decrease set-point or parameters ︽ ︾ Set the time and weekday: Touch this icon to set Minute/Hour and Weekday (1 = Monday, 2 = Tuesday etc.) Increase or decrease parameters by using the arrow ︽...
- Page 4 Products are warranted for 2 full year (checking and repairing services) from the date of purchase which products are not being damaged by any man-made factors. Service outwith the warranty period may incur an extra charge. More details please contact with Hotowell directly. Version 2018-1.0 - 4 -...
- Page 5 Smart Wifi Thermostat Reference No.:HTW-HT03 Series Wifi Connection Step 1- Download and Install APP Use your smart phone or tablet PC to scan the QR code below or Search “SMART LIFE” in the app store /Google play to download and install APP .
- Page 6 Smart Wifi Thermostat Reference No.:HTW-HT03 Series the thermostat screen and flashes once a sec. On the App Press the “+” on the upper right corner of the page (see Fig 3.1) or “Add Device” to add “Thermostat”. Click “Confirm indicator rapidly blink” (Fig 3.2) then select your network and back to your App to enter the password of your wireless router(Fig.3.3) and confirm.
- Page 7 Smart Wifi Thermostat Reference No.:HTW-HT03 Series The thermostat name can be edited after connection (fig 4.4). fig 4.1 fig 4.2 fig 4.3 fig 4.4 Operation Icons on APP App Icons Functions Switch thermostat power On or Off Lock/Unlock Icon. Locked=Green, Unlocked=Grey Economy mode.
- Page 8 Smart Wifi Thermostat Reference No.:HTW-HT03 Series Group Control and Info. Modify Press the menu button as fig 6.1, then click “Create Group”. Select all the rooms you want and confirm.(fig 6.2 and fig 6.3), edit the group name or ungroup as fig 6.3 and fig 6.4 Group Control allows to control all thermostats(+∞...
- Page 9 The M or Increase/Decrease button Make sure keypad is unlocked. doesn’t work Check that thermostat is on. Notice: Hotowell reserves all the right for the final explanation. The manual is subject to change without further notice. Version 2018-1.0 - 9 -...
