  • Page 1 Optix Series LCD Monitor Optix MAG341CQ (3MA0)
  • Page 2: Table Of Contents

    Contents Copyright and Trademarks Notice ��������������������������������������������������������������������������iii Revision ������������������������������������������������������������������������������������������������������������������iii Technical Support ���������������������������������������������������������������������������������������������������iii Safety Instructions ���������������������������������������������������������������������������������������������������iv CE Conformity ���������������������������������������������������������������������������������������������������������vi FCC-B Radio Frequency Interference Statement ���������������������������������������������������vi WEEE Statement ���������������������������������������������������������������������������������������������������vii Chemical Substances Information �������������������������������������������������������������������������vii RoHS Statement ����������������������������������������������������������������������������������������������������vii 1. Getting Started ........... 1-1 Package Contents ������������������������������������������������������������������������������������������������ 1-2 Installing the Monitor Stand ����������������������������������������������������������������������������������...
  • Page 3: Copyright And Trademarks Notice

    Preface Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co�, Ltd� All rights reserved� The MSI logo used is a registered trademark of Micro-Star Int’l Co�, Ltd� All other marks and names mentioned may be trademarks of their respective owners� No warranty as to accuracy or completeness is expressed or implied�...
  • Page 4: Safety Instructions

    Safety Instructions ◙ Read the safety instructions carefully and thoroughly� ◙ All cautions and warnings on the device or user’s manual should be noted� ◙ Refer servicing to qualified personnel only. Keep the User’s Guide that comes with the package for future reference� To prevent fire or shock hazard, keep this device away from humidity and high temperature�...
  • Page 5 Users should contact the local authorized point of collection for recycling and disposing of their end-of-life products� ◙ Visit the MSI website and locate a nearby distributor for further recycling information� ◙ Users may also reach us at gpcontdev@msi�com for information regarding proper disposal, take-back, recycling, and disassembly of MSI products�...
  • Page 6: Ce Conformity

    CE Conformity This device complies with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility (2014/30/EU), Low-voltage Directive (2014/35/EU), ErP Directive (2009/125/EC) and RoHS directive (2011/65/EU)� This product has been tested and found to comply with the harmonized standards for Information Technology Equipment published under Directives of Official Journal of the European Union�...
  • Page 7: Weee Statement

    Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products�...
  • Page 9: Getting Started

    Getting Started This chapter provides you with the information on hardware setup procedures� While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity� IMPORTANT • The illustrations are for reference only� Your monitor may vary in appearance� •...
  • Page 10: Package Contents

    Package Contents 1� Monitor 2� Stand 3� Stand Base with Screw 4� Power Cord 5� HDMI Cable 6� DisplayPort Cable 7� Quick Start Guide 8� Warranty Card * Contact your place of purchase or local distributor if any of the items is damaged or missing�...
  • Page 11: Installing The Monitor Stand

    Getting Started Installing the Monitor Stand 1� Fit the stand to the monitor and tighten the stand with the screws� 2� Place the protection cover� 3� Connect the base to the stand and tighten the base screw to secure the base� IMPORTANT Place the monitor on a soft, protected surface to avoid scratching the display panel�...
  • Page 12: Adjusting The Monitor

    Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment capabilities� IMPORTANT Avoid touching the display panel when adjusting the monitor�...
  • Page 13: Monitor Overview

    Getting Started Monitor Overview...
  • Page 14 Menu Key Select Key Select Key Enter Key Power Button LED Indicator: Blue: On Blinking Blue: Standby DVI Port HDMI Port DisplayPort Power Jack...
  • Page 15: Connecting The Monitor To Pc

    Getting Started Connecting the Monitor to PC 1� Turn off your computer. 2� Connect the DVI/HDMI/DisplayPort cable from the monitor to your computer� 3� Connect the power cord to the monitor power jack� (Figure A) 4� Plug the power cord into the electrical outlet� (Figure B) 5�...
  • Page 17: Osd Setup

    OSD Setup This chapter provides you with essential information on OSD Setup� IMPORTANT All information is subject to change without prior notice�...
  • Page 18: Osd Key

    OSD Key The monitor comes with a set of OSD Key that helps to control the On-Screen Display (OSD) menu�...
  • Page 19 OSD Setup Without entering OSD menu, you can use these OSD keys as hot keys for quick seetings� OSD Key Function Basic Operations Crosshair ■ Press button to enter this setting� ■ Press button to select� ■ Press button to confirm and exit. Mode ■...
  • Page 20: Osd Setup Menu

    OSD Setup Menu Press button to launch the On-Screen Display (OSD) main menu� In OSD screen, buttons to tune the desired function to suit your personal preferences� These OSD keys operations are as follows� OSD Key Basic Operations ■ Exiting the current menu ■...
  • Page 21 OSD Setup h Game 1st Level Menu 2nd/3rd Level Menu Description Mode User User mode� (Default) Movie Movie mode� First person shooting game mode� Strategic game mode� Eye Saver Less blue light mode� Turn on dynamic contrast function� Turn off dynamic contrast function. FreeSync Turn on FreeSync function�...
  • Page 22 h Input 1st Level Menu Description Select signal source from DVI port� HDMI Select signal source from HDMI port� Select signal source from DP port� h PIP/PBP 1st Level Menu 2nd/3rd Level Menu Description Source DVI / HDMI / DP PIP Size Small / Medium / Large Location...
  • Page 23: Appendix

    Appendix IMPORTANT All information is subject to change without prior notice�...
  • Page 24: Specifications

    Specifications Model Optix MAG341CQ Size 34 inch Curvature 1800R Panel Type Resolution 3440 x 1440@100Hz Aspect Ratio 21:9 Brightness (nits) Contrast Ratio 3000:1 Refresh Rate 100Hz Response Time 16ms (Typical) 8ms (GTG) Input Interface DVI x 1, HDMI 2�0 x1, DP x1 View Angles 178°(H) , 178°(V) NTSC...
  • Page 25: Preset Display Modes

    Appendix Preset Display Modes Optix MAG341CQ Resolution HDMI 640x480 @60Hz 640x480 @72Hz 640x480 @75Hz 800x600 @56Hz 800x600 @60Hz 800x600 @70Hz 800x600 @75Hz 800x600 @100Hz 1024x768 @60Hz 1024x768 @70Hz 1024x768 @75Hz 1024x768 @100Hz 1280x1024 @60Hz 1280x1024 @75Hz 1280x1024 @100Hz 1440x900 @60Hz 1440x900 @100Hz 1680x1050 @60Hz 1680x1050 @100Hz...
  • Page 26: Troubleshooting

    Troubleshooting The power LED is off. ■ Press the monitor power button again� ■ Check if the monitor power cable is properly connected� No image. ■ Check if the computer graphics card is properly installed� ■ Check if the computer and monitor are connected to electrical outlets and are turned on�...
