  • Page 1 Optix Series LCD Monitor Optix MPG341QR (3DB7) User Guide...
  • Page 2: Table Of Contents

    Contents Getting Started ......................3 Package Contents ....................3 Installing the Monitor Stand ................... 4 Adjusting the Monitor ..................... 5 Monitor Overview ....................6 Connecting the Monitor to PC ................8 OSD Setup ........................9 Navi Key ........................9 Hot Key ........................9 OSD Menus........................
  • Page 3: Getting Started

    Getting Started This chapter provides you with the information on hardware setup procedures. While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity. Package Contents Monitor Optix MPG341QR Quick Start Guide Documentation Stand with Screw(s) Stand Base with Screw(s)
  • Page 4: Installing The Monitor Stand

    Installing the Monitor Stand 1. Leave the monitor in its protective foam packaging. Align the stand bracket to the monitor groove. 2. Tighten the stand bracket with screws. 3. Connect the base to the stand and tighten the base screw to secure the base. 4.
  • Page 5: Adjusting The Monitor

    Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment capabilities. ⚠ Important Avoid touching the display panel when adjusting the monitor. ∙ ∙ Please slightly tilt the monitor backwards before pivoting it. 100mm Getting Started...
  • Page 6: Monitor Overview

    Monitor Overview Getting Started...
  • Page 7 Macro Key To activate OSD Application. Microphone Light Sensor Power Button / Power LED Lit in white after the monitor is turned on. If no signal input, the LED will turn into orange. Lit in orange when the monitor is in Stand-by mode. Cable Routing Hole Navi Key Kensington Lock...
  • Page 8: Connecting The Monitor To Pc

    Connecting the Monitor to PC 1. Turn off your computer. 2. Connect the video cable from the monitor to your computer. 3. Assemble the monitor power adapter & power cord. (Figure A) 4. Connect the power adapter to the monitor power jack. (Figure B) 5.
  • Page 9: Osd Setup

    OSD Setup This chapter provides you with essential information on OSD Setup. ⚠ Important All information is subject to change without prior notice. Navi Key The monitor comes with a Navi Key, a multi-directional control that helps navigate the On-Screen Display (OSD) menu. Up/Down/Left/Right: ∙...
  • Page 10: Osd Menus

    OSD Menus G.I. 1st Level Menu 2nd Level Menu Description Auto ∙ Through the internal Light Sensor Brightness and AI (Artificial Intelligence) Auto Control algorithm, this function detects the ambient light and Customize automatically sets the monitor to optimal brightness for users. ∙...
  • Page 11 Sound Tune ∙ Through the internal digital array microphone and AI algorithm, this function enables Active Noise Cancellation (ANC) technology. ∙ For Sound Tune to properly work, the computer needs to be connected to the USB Upstream port of the monitor. Auto ∙...
  • Page 12: Gaming

    Gaming 1st Level Menu 2nd/3rd Level Menu Description Game Mode User ∙ All items can be adjusted by users. ∙ Use Up or Down Button to select and preview mode effects. Racing ∙ Press the OK Button to confirm and apply your mode type.
  • Page 13: Professional

    1st Level Menu 2nd/3rd Level Menu Description Alarm Clock Location Left Top ∙ Users can adjust Alarm Clock in any mode. Right Top ∙ After setting the time, press the OK Button to activate the timer. Left Bottom ∙ Default Alarm Clock Location is Left Top.
  • Page 14: Image

    1st Level Menu 2nd Level Menu Description Low Blue Light ∙ Low Blue Light protects your eyes against blue light. When enabled, Low Blue Light adjusts the screen color temperature to a more yellow glow. ∙ Users can adjust Low Blue Light in any mode.
  • Page 15: Input Source

    1st Level Menu 2nd/3rd Level Menu Description Sharpness ∙ Users can adjust Sharpness in any mode. ∙ Sharpness improves clarity and details of images. Color Cool ∙ Color Temperature default is Temperature Normal. Normal ∙ Use Up or Down Button to select and preview mode effects.
  • Page 16: Pip/Pbp

    PIP/PBP 1st Level Menu 2nd/3rd Level Menu Description ∙ PIP (Picture in Picture) allows users to simultaneously display Source HDMI1 multiple video sources on one HDMI2 screen. One program is displayed on the full screen at the same time as one or more other Type-C programs are displayed in inset windows.
  • Page 17: Navi Key

    Navi Key 1st Level Menu 2nd Level Menu Description Up/Down/Left/ ∙ Up Button default is Game Mode. Right ∙ Down Button default is Smart Crosshair. Brightness ∙ Left Button default is KVM. Game Mode ∙ Right Button default is Input Source. Smart Crosshair ∙...
  • Page 18: Setting

    Setting 1st Level Menu 2nd Level Menu Description Language 繁體中文 ∙ Language factory default is English. ∙ Users have to press the OK Button to English confirm and apply the Language setting. Français ∙ Language is an independent setting. Users’ own language setting will override Deutsch the factory default.
  • Page 19 1st Level Menu 2nd Level Menu Description HDMI CEC ∙ Default is OFF. ∙ HDMI CEC (Consumer Electronics Control) supports Sony PlayStation®, Nintendo® Switch™, Xbox Series X|S consoles and various audio-visual devices that are CEC- capable. ∙ If HDMI CEC is set to ON: • The monitor will automatically power on when the CEC device is turned on.
  • Page 20: Specifications

    Specifications Model Optix MPG341QR Size 34 inch Curvature Flat Panel Type Resolution 3440 x 1440 @144Hz 21:9 Aspect Ratio Brightness (nits) 550 (typ.) ∙ 0~69%: 5V/3A Brightness: USB Type-C ∙ 70~89%: 5V/3A Power Delivery ∙ 90~100%: 5V/3A Contrast Ratio 1000:1 Refresh Rate 144Hz Response Time...
  • Page 21 Model Optix MPG341QR Adjustment (Tilt) -5° ~ 20° Adjustment (Height) 0 ~ 100mm Adjustment (Swivel) -30° ~ 30° Kensington Lock ∙ Plate Type: 100 x 100 mm ∙ Screw Type: M4 x 10 mm VESA Mounting • Thread Diameter: 4 mm • Thread Pitch: 0.7 mm • Thread Length: 10 mm Dimension (W x H x D)
  • Page 22: Preset Display Modes

    Preset Display Modes Optix MPG341QR Standard Resolution HDMI DP/ Type-C 2560x1440 @60Hz @120Hz WQHD 3440x1440 @50Hz @60Hz @100Hz @120Hz @144Hz Optix MPG341QR Video Timing Mode Resolution HDMI DP/ Type-C 720P 1080P @60Hz @120Hz 2160P @30Hz @60Hz 2560x1080p @60Hz @120Hz Preset Display Modes...
  • Page 23: Troubleshooting

    Troubleshooting The power LED is off. • Press the monitor power button again. • Check if the monitor power cable is properly connected. No image. • Check if the computer graphics card is properly installed. • Check if the computer and monitor are connected to electrical outlets and are turned on.
  • Page 24: Safety Instructions

    ∙ Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. ∙ If this device comes with an adapter, use only the MSI provided AC adapter approved for use with this device.
  • Page 25 California, USA: The button cell battery may contain perchlorate material and requires special handling when recycled or disposed of in California. For further information please visit: https://dtsc.ca.gov/perchlorate/ Environment ∙ To reduce the possibility of heat-related injuries or of overheating the device, do not place the device on a soft, unsteady surface or obstruct its air ventilators.
  • Page 26: Tüv Rheinland Certification

    TÜV Rheinland Certification TÜV Rheinland Low Blue Light Certification Blue light has been shown to cause eye fatigue and discomfort. MSI now offers monitors with TÜV Rheinland Low Blue Light certification to ensure users’ eye comfort and well-being. Please follow the instructions below to reduce the symptoms from extended exposure to the screen and blue light.
  • Page 27: Regulatory Notices

    1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626) 913-0828 www.msi.com...
  • Page 28 Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products.
  • Page 29 Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners.
