Siemens SIMATIC NET RUGGEDCOM RX1511 Installation Manual page 24

RUGGEDCOM RX1511
Installation Manual, 12/2019, C79000-G8976-1056-16
Figure 2.9 DC Terminal Block Wiring – Screw Terminal Block for 12P, 24P and 48P Power
Supplies
Not Connected
1
European-style (Euroblock) Terminal Block
2
Positive (+) Terminal
3
Negative (-) Terminal
4
Ground Terminal
5
Figure 2.10 DC Terminal Block Wiring – European-style (Euroblock) Terminal Block for
-12P, -24P and -48P Power Supplies
2
Not Connected
1
Removable Screw Terminal Block
2
Non-removable Screw Terminal Block
3
Positive (+) Terminal
4
Negative (-) Terminal
5
2.5.2 Connecting Low DC Power
1
2
3
4
4
1
5
1
6
Installing the Device
3
4
5
6
15
